High/low bus circuit for Mercedes-Benz E-class W214/S214 (2023-2024)
High/low bus circuit (1 of 6)
AUGMENTED REALITY CAMERA
BRN WIRE
CAN H H
CAN H L
CAN HMI H
CAN HMI L
CAN L
CAN-H
ELECTRICAL POWER STEERING CONTROL UNIT
FLEX-E BM
FLEX-E BP
GRN WIRE
GRN/WHT WIRE
HEAD-UP DISPLAY
INTELLIGENT DRIVE CONTROL UNIT
LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
LEFT OUTER FRONT BUMPER RADAR SENSOR
LEFT OUTER REAR BUMPER RADAR SENSOR (BEHIND LEFT END OF REAR BUMPER FASCIA)
PNK WIRE
RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
RIGHT OUTER FRONT BUMPER RADAR SENSOR
RIGHT OUTER REAR BUMPER RADAR SENSOR
STEREO MULTI-FUNCTION CAMERA (TOP CENTER OF WINDSHIELD)
SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT
TIRE PRESSURE MONITOR CONTROL UNIT
USER INTERFACE CAN (CAN HMI) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR
VIO WIRE
VIO/WHT WIRE
High/low bus circuit (2 of 6)
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
CAN H H
CAN HMI H
CAN HMI L
CAN L
CAN PER H
CAN PER L
CAN-H
CAN-H L PNK FLEX-E BM WIRE
ELECTRONIC IGNITION SWITCH CONTROL UNIT
ELECTRONIC STABILITY PROGRAM CONTROL UNIT
FLEX-E BM
FLEX-E BP
FLEX-E BP PNK FLEX-E BM WIRE
GRN WIRE
GRN/WHT WIRE
INSTRUMENT CLUSTER CONTROL UNIT
LEFT FRONT LAMP UNIT
LEFT OUTER REAR BUMPER INTEGRATED RADAR SENSOR
MONO MULTI-FUNCTION CAMERA
PERIPHERALS CAN (CAN PER) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR
PNK FLEX-E BM WIRE
PNK WIRE
RIGHT FRONT LAMP UNIT
RIGHT OUTER REAR BUMPER INTEGRATED RADAR SENSOR
STEERING COLUMN MODULE CONTROL UNIT
VIO WIRE
VIO/WHT WIRE
YEL WIRE
YEL/BLK WIRE
High/low bus circuit (3 of 6)
BLK WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
CAN L
CAN-H
DRIVER SEAT CONTROL UNIT
FRONT SAM CONTROL UNIT (LEFT END OF DASH)
GRN WIRE
GRN/WHT WIRE
LEFT FRONT DOOR CONTROL UNIT (IN LEFT FRONT DOOR)
LEFT FRONT MULTICONTOUR SEAT CONTROL UNIT
LEFT INTERIOR CAN (CAN B) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR
LEFT REAR DOOR CONTROL UNIT (IN LEFT REAR DOOR)
LIN
PANORAMIC SLIDING SUNROOF CONTROL MODULE
PNK WIRE
RAIN/LIGHT SENSOR W/ ADDITIONAL FUNCTIONS
YEL WIRE
YEL/BLK WIRE
High/low bus circuit (4 of 6)
ACTIVE BRAKE ASSIST CONTROLLER UNIT
ACTIVE DISTANCE ASSIST DISTRONIC ELECTRIC CONTROLLER UNIT
AIR BODY CONTROL PLUS CONTROL UNIT
AIR BODY CONTROL UNIT (WAGON) (LEFT SIDE OF LUGGAGE COMPT)
AUDIO/COMAND CONTROL PANEL
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/RED WIRE
CAN A H
CAN A L
CAN L
CAN-H
FLEX PNK FLEX WIRE
FLEX-E BM
FLEX-E BP
FRONT MOBILE PHONE CRADLE CONTROL UNIT
GRN WIRE
GRN/WHT WIRE
HEAD UNIT
HEAD UNIT/INSTRUMENT CLUSTER DISPLAY CLUSTER
LEFT LOWER CONTROL PANEL
LIN
ORG/ WIRE
PARKING SYSTEM CONTROL UNIT
PNK WIRE
RIGHT LOWER CONTROL PANEL
SEDAN
UPPER CONTROL PANEL CONTROL UNIT
WAGON
WHT WIRE
YEL WIRE
YEL/BLK WIRE
High/low bus circuit (5 of 6)
ARMREST HEATER CONTROL UNIT
BLU WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
CAN C H
CAN C L
CAN L H
CAN L L
CAN PER H
CAN PER L
DRIVETRAIN CONTROL UNIT (ABOVE LEFT FRONT WHEELWELL)
FLEX-E BM
FLEX-E BP
FUEL PUMP CONTROL UNIT
FULLY INTEGRATED TRANSMISSION CONTROL CONTROLLER UNIT
GRN WIRE
GRN/WHT WIRE
HYBRID CAN (CAN L) POTENTIAL DISTRIBUTION ELECTRICAL CONNECTOR
ME-SFI (ME) CONTROL UNIT
NCA WIRE
ORG/ WIRE
ORG/WHT WIRE
PNK WIRE
REAR SEAT HEATERS CONTROL UNIT
SOUND SYSTEM AMPLIFIER CONTROL UNIT
STARTER GENERATOR CONTROL UNIT
WAGON
High/low bus circuit (6 of 6)
AMBIANCE ILLUMINATION CONTROL UNIT
BLU WIRE
BLU/GRY WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
CLIMATE CONTROL UNIT (RIGHT SIDE OF DASH)
FRONT PASSENGER SEAT CONTROL UNIT
FRONT PASSENGER'S SEATBACK)
GRN WIRE
KEYLESS GO CONTROL UNIT (RIGHT SIDE OF LUGGAGE COMPT)
MULTICONTOUR SEAT PNEUMATIC PUMP
OVERHEAD CONTROL PANEL CONTROL UNIT
REAR SAM CONTROL UNIT (RIGHT REAR OF LUGGAGE COMPT)
REAR SWITCHING MODULE
RED WIRE
RIGHT FRONT DOOR CONTROL UNIT (IN RIGHT FRONT DOOR)
RIGHT FRONT MULTICONTOUR SEAT CONTROL UNIT
RIGHT INTERIOR CAN (CAN B) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR
RIGHT REAR DOOR CONTROL UNIT (IN RIGHT REAR DOOR)
