Mercedes-Benz E-class W213/S213/C238/A238 facelift (2020-2024) computer data lines system Wiring diagrams
This page contains all the electrical diagrams for the component. computer data lines system, in which he is found in the car Mercedes-Benz E-class W213/S213/C238/A238 facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
computer data lines system wiring diagram (131 of 373)
AIRSCARF CONTROL UNIT
BLU WIRE
BLU/YEL WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN-B L AAG
COMPUTER DATA LINES SYSTEM
DRIVER-SIDE FUSE, RELAY MODULE
FUSE 209
FUSE 425
FUSE 426
GRN/YEL WIRE
H LEFT
H RIGHT
HOT AT ALL TIMES
LEFT AIRSCARF FAN MOTOR
LIN 1
ORG/ WIRE
REAR FUSE, RELAY MODULE
REAR SAM CONTROL UNIT
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT AIRSCARF FAN MOTOR
SIG
STATUS
STATUS 2
UPPER CONTROL PANEL CONTROL UNIT
WHT/BLU WIRE
WHT/ORG WIRE
Go to component -> Airscarf system circuit -> COMPUTER DATA LINES SYSTEM
computer data lines system wiring diagram (132 of 373)
AAG
ARMREST HEATER CONTROL UNIT
BLK WIRE
BLU/GRY WIRE
BRN WIRE
BRN/RED WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
DRIVER-SIDE FUSE, RELAY MODULE
FUSE 203
FUSE 214
FUSE 301
FUSE 302
FUSE 425
GRN WIRE
GRN/GRY WIRE
HOT AT ALL TIMES
LEFT FRONT CENTER CONSOLE ARMREST HEATING ELEMENT
LEFT FRONT DOOR ARMREST HEATING ELEMENT
LEFT FRONT DOOR CONTROL UNIT
LEFT REAR DOOR CONTROL UNIT
LEFT REAR SEAT ARMREST HEATING ELEMENT
NCA WIRE
PASSENGER-SIDE A-PILLAR FUSE BOX
REAR FUSE, RELAY MODULE
REAR SAM CONTROL UNIT
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT CENTER CONSOLE ARMREST HEATING ELEMENT
RIGHT FRONT DOOR ARMREST HEATING ELEMENT
RIGHT FRONT DOOR CONTROL UNIT
RIGHT REAR DOOR CONTROL UNIT
RIGHT REAR SEAT ARMREST HEATING ELEMENT
SIG
Go to component -> Armrest heated circuit, wagon -> COMPUTER DATA LINES SYSTEM
computer data lines system wiring diagram (133 of 373)
BLK/WHT WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
DRIVER SEAT CONTROL UNIT
DRIVER-SIDE FUSE, RELAY MODULE
FUSE 203
FUSE 302
FUSE 303
FUSE 304
HOT AT ALL TIMES
LEFT FRONT DOOR CONTROL UNIT
LEFT FRONT SEAT ADJUSTABLE SEAT CUSHION LENGTH HEATER PAD
LEFT FRONT SEAT BACKREST HEATER PAD
LEFT FRONT SEAT BACKREST SIDE BOLSTER HEATER PAD
LEFT FRONT SEAT BACKREST SIDE BOLSTER HEATER PAD TEMPERATURE SENSOR
LEFT FRONT SEAT CLIMATE CONTROL SWITCH GROUP LEFT FRONT SEAT HEATER SWITCH
LEFT FRONT SEAT CUSHION HEATER PAD
LEFT FRONT SEAT CUSHION SIDE BOLSTER HEATER PAD
LEFT FRONT SEAT CUSHION SIDE BOLSTER HEATER PAD TEMPERATURE SENSOR
LEFT FRONT SEAT VENTILATION SWITCH
LEFT/RIGHT SEAT SETTING SWITCH
NCA WIRE
PASSENGER-SIDE A-PILLAR FUSE BOX
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SIG
VIO WIRE
W/ SEAT HEATER PLUS
W/O SEAT HEATER PLUS
Go to component -> Front ventilation & heated seat circuit, convertible w/ memory (1 of 3) -> COMPUTER DATA LINES SYSTEM
computer data lines system wiring diagram (134 of 373)
BLK/WHT WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
DRIVER SEAT CONTROL UNIT
DRIVER-SIDE FUSE, RELAY MODULE
FUSE 203
FUSE 302
FUSE 303
FUSE 304
HOT AT ALL TIMES
LEFT FRONT DOOR CONTROL UNIT
LEFT FRONT SEAT ADJUSTABLE SEAT CUSHION LENGTH HEATER PAD
LEFT FRONT SEAT BACKREST HEATER PAD
LEFT FRONT SEAT BACKREST SIDE BOLSTER HEATER PAD
LEFT FRONT SEAT BACKREST SIDE BOLSTER HEATER PAD TEMPERATURE SENSOR
LEFT FRONT SEAT CLIMATE CONTROL SWITCH GROUP LEFT FRONT SEAT HEATER SWITCH
LEFT FRONT SEAT CUSHION HEATER PAD
LEFT FRONT SEAT CUSHION SIDE BOLSTER HEATER PAD
LEFT FRONT SEAT CUSHION SIDE BOLSTER HEATER PAD TEMPERATURE SENSOR
LEFT FRONT SEAT VENTILATION SWITCH
LEFT/RIGHT SEAT SETTING SWITCH
NCA WIRE
PASSENGER-SIDE A-PILLAR FUSE BOX
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SIG
VIO WIRE
W/ SEAT HEATER PLUS
W/O SEAT HEATER PLUS
Go to component -> Front ventilation & heated seat circuit, coupe w/ memory (1 of 3) -> COMPUTER DATA LINES SYSTEM
computer data lines system wiring diagram (135 of 373)
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER SEAT CONTROL UNIT
MOT (+) MOT GND
NCA WIRE
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR CONTROL UNIT
RIGHT FRONT SEAT ADJUSTABLE SEAT CUSHION LENGTH HEATER PAD
RIGHT FRONT SEAT ADJUSTMENT SWITCH GROUP
RIGHT FRONT SEAT BACKREST BOLSTER HEATER PAD
RIGHT FRONT SEAT BACKREST HEATER PAD
RIGHT FRONT SEAT BACKREST SIDE BOLSTER HEATER PAD TEMPERATURE SENSOR
RIGHT FRONT SEAT CUSHION HEATER PAD
RIGHT FRONT SEAT CUSHION SIDE BOLSTER HEATER PAD
RIGHT FRONT SEAT CUSHION SIDE BOLSTER HEATER PAD TEMPERATURE SENSOR
SIG
VIO WIRE
W/ SEAT HEATER PLUS
W/O SEAT HEATER PLUS
Go to component -> Front ventilation & heated seat circuit, sedan w/ memory (3 of 3) -> COMPUTER DATA LINES SYSTEM
computer data lines system wiring diagram (136 of 373)
BLK/WHT WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
DRIVER SEAT CONTROL UNIT
DRIVER-SIDE FUSE, RELAY MODULE
FUSE 203
FUSE 302
FUSE 303
FUSE 304
HOT AT ALL TIMES
LEFT FRONT DOOR CONTROL UNIT
LEFT FRONT SEAT ADJUSTABLE SEAT CUSHION LENGTH HEATER PAD
LEFT FRONT SEAT BACKREST HEATER PAD
LEFT FRONT SEAT BACKREST SIDE BOLSTER HEATER PAD
LEFT FRONT SEAT BACKREST SIDE BOLSTER HEATER PAD TEMPERATURE SENSOR
LEFT FRONT SEAT CLIMATE CONTROL SWITCH GROUP
LEFT FRONT SEAT CUSHION HEATER PAD
LEFT FRONT SEAT CUSHION SIDE BOLSTER HEATER PAD
LEFT FRONT SEAT CUSHION SIDE BOLSTER HEATER PAD TEMPERATURE SENSOR
MOT (+) MOT GND
MOT GND/(+)
NCA WIRE
PASSENGER-SIDE A-PILLAR FUSE BOX
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SIG
VIO WIRE
W/ SEAT HEATER PLUS
W/O SEAT HEATER PLUS
Go to component -> Front ventilation & heated seat circuit, wagon w/ memory (1 of 3) -> COMPUTER DATA LINES SYSTEM
computer data lines system wiring diagram (137 of 373)
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER SEAT CONTROL UNIT
MOT (+) MOT GND
NCA WIRE
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR CONTROL UNIT
RIGHT FRONT SEAT ADJUSTABLE SEAT CUSHION LENGTH HEATER PAD
RIGHT FRONT SEAT ADJUSTMENT SWITCH GROUP
RIGHT FRONT SEAT BACKREST BOLSTER HEATER PAD
RIGHT FRONT SEAT BACKREST HEATER PAD
RIGHT FRONT SEAT BACKREST SIDE BOLSTER HEATER PAD TEMPERATURE SENSOR
RIGHT FRONT SEAT CUSHION HEATER PAD
RIGHT FRONT SEAT CUSHION SIDE BOLSTER HEATER PAD
RIGHT FRONT SEAT CUSHION SIDE BOLSTER HEATER PAD TEMPERATURE SENSOR
SIG
VIO WIRE
W/ SEAT HEATER PLUS
W/O SEAT HEATER PLUS
Go to component -> Front ventilation & heated seat circuit, wagon w/ memory (3 of 3) -> COMPUTER DATA LINES SYSTEM
computer data lines system wiring diagram (138 of 373)
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN B H
CAN B L
CAN-B H AAG
COMPUTER DATA LINES SYSTEM
DRIVER-SIDE FUSE, RELAY MODULE
FRONT SEAT HEATER/SEAT VENTILATION CONTROL UNIT
FUSE 203
FUSE 306
HOT AT ALL TIMES
LEFT FRONT BACKREST SEAT VENTILATION MOTORS
LEFT FRONT DOOR CONTROL UNIT
LEFT FRONT SEAT ADJUSTABLE SEAT CUSHION LENGTH HEATER PAD
LEFT FRONT SEAT BACKREST HEATER PAD
LEFT FRONT SEAT CLIMATE CONTROL SWITCH GROUP
LEFT FRONT SEAT CUSHION HEATER PAD
LEFT FRONT SEAT CUSHION SEAT VENTILATION MOTORS
LEFT FRONT SEAT HEATER SWITCH
LEFT FRONT SEAT VENTILATION SWITCH
NCA WIRE
PASSENGER-SIDE A-PILLAR FUSE BOX
REAR SAM CONTROL UNIT
RED WIRE
RED/BLK WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
VIO WIRE
W/ SEATING COMFORT PACKAGE
Go to component -> Front ventilation & heated seat circuit, wagon w/o memory (1 of 2) -> COMPUTER DATA LINES SYSTEM
computer data lines system wiring diagram (139 of 373)
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER-SIDE FUSE, RELAY MODULE
FANFARE HORNS, AIR BAG CLOCKSPRING CONTACT
FLEX-E BP PNK FLEX-E BM WIRE
FUSE 205
GRN WIRE
HEATING ELEMENT TEMPERATURE SENSOR
HOT AT ALL TIMES
LH -
NCA WIRE
RED/BLU WIRE
STEERING COLUMN ADJUSTMENT, STEERING WHEEL HEATER SWITCH
STEERING COLUMN MODULE CONTROL UNIT
STEERING WHEEL ELECTRONICS
STEERING WHEEL HEATER
STEERING WHEEL HEATER HEATING ELEMENT
STEERING WHEEL HEATER INDICATOR LAMP
Go to component -> Heated steering wheel circuit, coupe -> COMPUTER DATA LINES SYSTEM
computer data lines system wiring diagram (140 of 373)
BRN WIRE
CAN LR H
CAN LR L
COMPUTER DATA LINES SYSTEM
DRIVER-SIDE FUSE, RELAY MODULE
FANFARE HORNS, AIR BAG CLOCKSPRING CONTACT
FLEX-E BP PNK FLEX-E BM WIRE
FUSE 205
GRN WIRE
HEATING ELEMENT TEMPERATURE SENSOR
HOT AT ALL TIMES
NCA WIRE
RED/BLU WIRE
SENS GND
SIG
STEERING COLUMN ADJUSTMENT, STEERING WHEEL HEATER SWITCH
STEERING COLUMN MODULE CONTROL UNIT
STEERING WHEEL ELECTRONICS
STEERING WHEEL HEATER
STEERING WHEEL HEATER HEATING ELEMENT
STEERING WHEEL HEATER INDICATOR LAMP
TEMP
Go to component -> Heated steering wheel circuit, sedan -> COMPUTER DATA LINES SYSTEM
