Headlights circuit, w/ static led headlamps for Mercedes-Benz E-class W213/S213/C238/A238 (2016-2021)

BLK WIRE BLU WIRE BRN WIRE BRN/RED WIRE CAN B H CAN B L CAN H H CAN H L CAN HMI H CAN HMI L COC COMPUTER DATA LINES SYSTEM DRIVER-SIDE FUSE, RELAY MODULE ELECTRIC PARKING BRAKE SWITCH (LEFT END OF DASH) ELECTRONIC STABILITY PROGRAM CONTROL UNIT ENGINE FUSE, RELAY MODULE EXTERIOR LIGHTS SWITCH FRONT SAM CONTROL UNIT FUSE 110 FUSE 128 FUSE 133 FUSE 200 FUSE 205 FUSE 305 GRN WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT W/ ENGINE COMPARTMENT TERMINAL 15 RELAY ENERGIZED INSTRUMENT CLUSTER OVERHEAD CONSOLE PASSENGER-SIDE A-PILLAR FUSE BOX PNK WIRE PNK/RED WIRE RAIN/LIGHT SENSOR W/ ADDITIONAL FUNCTIONS RED (OR RED/BLU) WIRE RED WIRE RED/YEL WIRE SEDAN, WAGON COUPE, CONVERTIBLE SIG SIG (1) SIG (2) SIG 3 VIO WIRE VIO/WHT WIRE YEL WIRE

BLK/BRN WIRE BRN WIRE CAN PER H CAN PER L COMBINATION SWITCH COMPUTER DATA LINES SYSTEM FLEX-E BM FLEX-E BP GRN WIRE GRN/WHT WIRE HEADLAMP FLASHER/ HIGH BEAM SWITCH LEFT FRONT LAMP UNIT LEFT HEADLAMP CONTROL UNIT LEFT HEADLAMP RANGE ADJUSTMENT ACTUATOR MOTOR LEFT HIGH BEAM LEFT LED SIGNALING LIGHTS ACTUATION MODULE FAN MOTOR LEFT LOW BEAM LEFT REAR LEVEL SENSOR PNK WIRE PNK/RED WIRE RED WIRE RED/YEL WIRE RIGHT FRONT LAMP UNIT RIGHT HEADLAMP CONTROL UNIT RIGHT HEADLAMP RANGE ADJUSTMENT ACTUATOR MOTOR RIGHT HIGH BEAM RIGHT LED SIGNALING LIGHTS ACTUATION MODULE FAN MOTOR RIGHT LOW BEAM SIG STEERING COLUMN MODULE CONTROL UNIT WHT/BLK WIRE
