Mercedes-Benz E-class W212/S212/C207/A207 facelift (2013-2016) Headlights circuit, wagon w/ dynamic led headlamps

BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE CAN B H CAN B L CAN-G H CAN-G L COMBINATION SWITCH COMPUTER DATA LINES SYSTEM EXTERIOR LIGHTS SWITCH FRONT FOG LAMP BUTTON FRONT FOG LAMPS INDICATOR LAMP FRONT SAM CONTROL MODULE W/ FUSE/ RELAY MODULE FUSE 1 FUSE 5 FUSE BOX GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY WIRE HEADLAMP FLASHER/ HIGH BEAM SWITCH LOW BEAM SWITCH HIGH BEAM INDICATOR LAMP HOT AT ALL TIMES HOT W/ CIRCUIT 15 RELAY ENERGIZED INSTRUMENT CLUSTER LEFT "C" PILLAR) LEFT FOG LAMP LEFT FRONT LEVEL SENSOR LEFT REAR FOG LAMP LEFT REAR LEVEL SENSOR LOW BEAM INDICATOR LAMP PARKING BRAKE INDICATOR SWITCH REAR FOG LAMP INDICATOR LAMP REAR FOG LIGHT BUTTON RED WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RIGHT FOG LAMP RIGHT REAR FOG LAMP SEDAN SIG SML STEERING COLUMN MODULE CONTROL UNIT SWITCH ILLUMINATION WAGON WHT/RED WIRE YEL WIRE YEL/VIO WIRE YEL/WHT WIRE

BLK/RED WIRE BRN WIRE BRN/WHT WIRE FUSE 74 FUSE 75 GRN/BLK WIRE GRN/WHT WIRE HOT AT ALL TIMES LEFT ACTIVE CURVE ILLUMINATION ACTUATOR MOTOR LEFT FRONT EXTERIOR LIGHTS LED ACTUATION MODULE LEFT FRONT LAMP UNIT LEFT FRONT VARIO-LED LAMP UNIT LEFT HEADLAMP CONTROL UNIT LEFT HEADLAMP RANGE ADJUSTMENT ACTUATOR MOTOR LEFT LED SIGNALING LIGHTS ACTUATION MODULE FAN MOTOR LEFT LIGHT DISTRIBUTION ACTUATOR MOTOR REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE YEL WIRE YEL/WHT WIRE

BLK/RED WIRE BRN WIRE BRN/GRY WIRE BRN/RED WIRE CAN B H CAN B L COMPUTER DATA LINES SYSTEM GRY/YEL WIRE LIN 2 OVERHEAD CONTROL PANEL ELECTRONICS RAIN/LIGHT SENSOR RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT ACTIVE CURVE ILLUMINATION ACTUATOR MOTOR RIGHT FRONT EXTERIOR LIGHTS LED ACTUATION MODULE RIGHT FRONT LAMP UNIT RIGHT FRONT VARIO-LED LAMP UNIT RIGHT HEADLAMP CONTROL UNIT RIGHT HEADLAMP RANGE ADJUSTMENT ACTUATOR MOTOR RIGHT LED DRIVING LIGHTS ACTUATION MODULE FAN MOTOR RIGHT LIGHT DISTRIBUTION ACTUATOR MOTOR YEL WIRE YEL/WHT WIRE
