Mercedes-Benz E-class W212/S212/C207/A207 facelift (2013-2016) Electronic power steering circuit, sedan

17 18 CAN B L CAN B H BRN WIRE BRN/RED WIRE CAN B H CAN B L COMPUTER DATA LINES SYSTEM ELECTRIC POWER STEERING ACTUATOR MOTOR ELECTRIC POWER STEERING TORQUE SENSOR ELECTRICAL POWER STEERING CONTROL UNIT ELECTRICAL POWER STEERING CONTROL UNIT (ON STEERING RACK ASSEMBLY) FRONT ELECTRICAL PREFUSE BOX FRONT ELECTRICAL PREFUSE BOX (RIGHT REAR OF ENGINE COMPT) FUSE FUSE 151 FUSE 157 GND PAS A GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER NCA WIRE PAS A RED WIRE W/O ECO START/STOP FUNCTION W/ ECO START/STOP FUNCTION
