Mercedes-Benz E-class W212/S212/C207/A207 facelift (2013-2016) Electronic power steering circuit, coupe

17 18 CAN B L CAN B H BRN WIRE BRN/RED WIRE CAN B H CAN B L COMPUTER DATA LINES SYSTEM ELECTRIC POWER STEERING ACTUATOR MOTOR ELECTRIC POWER STEERING ELECTROMECHANICAL CONTROLLER UNIT ELECTRIC POWER STEERING TORQUE SENSOR ELECTRICAL POWER STEERING CONTROL UNIT ELECTRICAL POWER STEERING CONTROL UNIT (ON STEERING RACK ASSEMBLY) FRONT ELECTRICAL PREFUSE BOX FRONT ELECTRICAL PREFUSE BOX (RIGHT REAR OF ENGINE COMPT) FUSE FUSE 157 HOT AT ALL TIMES INSTRUMENT CLUSTER RED WIRE YEL WIRE YEL/WHT WIRE
