Tire pressure monitoring circuit for Mercedes-Benz E-class W212/S212/C207/A207 (2009-2013)

BRN WIRE BRN/RED WIRE CAN B H CAN B H CAN E H CAN B L CAN E L CAN B L COMPUTER DATA LINES SYSTEM COUPE, SEDAN DRIVER SIDE SAM CONTROL MODULE FUSE 28 W/ FUSE, RELAY MODULE (LEFT REAR OF ENGINE COMPT) GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER LEFT FRONT TIRE PRESSURE SENSOR (LEFT FRONT WHEEL/TIRE ASSEMBLY) LEFT REAR TIRE PRESSURE SENSOR (LEFT REAR WHEEL/TIRE ASSEMBLY) RED/GRN WIRE RED/YEL WIRE RIGHT FRONT TIRE PRESSURE SENSOR (RIGHT FRONT WHEEL/TIRE ASSEMBLY) RIGHT REAR TIRE PRESSURE SENSOR (RIGHT REAR WHEEL/TIRE ASSEMBLY) SEDAN SEDAN, COUPE TIRE PRESSURE MONITOR (TPM) CONTROL UNIT (LEFT REAR OF TRUNK) TIRE PRESSURE MONITOR WARNING LAMP
