Mercedes-Benz E-class W212/S212/C207/A207 (2009-2013) navigation processor Wiring diagram
This page shows the only wiring diagram for the component.navigation processor, which is found in the car Mercedes-Benz E-class W212/S212/C207/A207 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram navigation processor (1 of 1)
2 LCT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BREAKDOWN ASSISTANCE BUTTON
BRN WIRE
BRN/GRN WIRE
CAN D H CAN D L
CENTER INSTRUMENT PANEL SPEAKER
COMAND CONTROL UNIT (IF EQUIPPED)
COMPUTER DATA LINES SYSTEM
DIAGNOSTIC CONNECTOR
DRIVER SIDE SAM CONTROL MODULE W/ FUSE/ RELAY MODULE (LEFT REAR OF ENGINE COMPT)
EMERGENCY CALL SYSTEM ANTENNA (PACKAGE SHELF)
EMERGENCY CALL SYSTEM BUTTON
EMERGENCY CALL SYSTEM CONTROL UNIT (CENTER OF TRUNK)
FUSE 83 W/ FUSE, RELAY MODULE (LEFT SIDE OF TRUNK)
FUSE 87
GPS
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT W/ CIRCUIT
MB INFO BUTTON
MB-INFO, BREAKDOWN ASSISTANCE BUTTON
MIC + MIC -
MOBILE PHONE ELECTRICAL CONNECTOR (IF EQUIPPED),
MOBILE PHONE, STATIONARY HEATER RADIO REMOTE CONTROL ANTENNA SPLITTER (TRUNK)
MULTI-FUNCTION ANTENNA
MUTE
NAVIGATION PROCESSOR
NCA WIRE
OVERHEAD CONTROL PANEL CONTROL MODULE (W/ POWER TILTING/
PNK/GRN WIRE
POWER DISTRIBUTION SYSTEM
REAR SAM CONTROL MODULE
RED/BLK WIRE
SHIELD ANT GPS
SIG SHIELD ANT NOT SHIELD
SOUND SYSTEM AMPLIFIER CONTROL UNIT
SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT
TEL
VIO WIRE
W/ BLUETOOTH
W/ COMAND
W/O BLUETOOTH
W/O BLUETOOTH (W/ BLUETOOTH)
W/O COMAND
WHT WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Emergency call circuit, sedan -> NAVIGATION PROCESSOR
