Data link connector circuit for Mercedes-Benz E-class W211/S211 facelift (2006-2009)

1 2 3 CAN-D L CAN-D H SHIELD BLK/GRY WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/RED WIRE CAN-D H CAN-D L CAN-D L CAN-D H 30 CAN-C L CAN-C H CAN-B L CAN-B H CDI CONTROL MODULE (3.OL TURBO) (LEFT REAR OF ENGINE COMPT) ME-SFI (ME) CENTRAL GATEWAY CONTROL MODULE (UNDER LEFT SIDE OF DASH) CIRCUIT 15 VOLTAGE DISTRIBUTOR CONTROL MODULE (3.5L) (CENTER REAR OF ENGINE COMPT) DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH) DIAG DRIVER SIDE SAM CONTROL EMERGENCY CALL SYSTEM CONTROL UNIT (CENTER OF TRUNK) ESP/SPS/BAS CONTROL MODULE (LEFT REAR OF ENGINE COMPT) GRN WIRE GRN/WHT WIRE HIGH/LOW BUS CIRCUIT HOT AT ALL TIMES FUSE 30 HOT AT ALL TIMES FUSE 41 INTERIOR FUSE BOX (LEFT END OF DASH) MODULE W/ FUSE, RELAY MODULE (LEFT REAR OF ENGINE COMPT) NCA WIRE PASSENGER SIDE SAM CONTROL MODULE REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE (LEFT SIDE OF TRUNK) RED/WHT WIRE RED/YEL WIRE SHIELD UPPER CONTROL PANEL CONTROL MODULE WHT WIRE YEL/RED WIRE
