Mercedes-Benz E-class W211/S211 facelift (2006-2009) lower control field control module Wiring diagrams
This page contains all the electrical diagrams for the component. lower control field control module, in which he is found in the car Mercedes-Benz E-class W211/S211 facelift (2006-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram lower control field control module (1 of 3)
1 2 3 4 5 6 DTR CONTROL MODULE
1 2 3 4 CAN-B L CAN-B H 31 30
BRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DTR DISTANCE POTENTIOMETER
DTR SWITCH
FUSE 39
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
INTERIOR FUSE BOX (LEFT END OF DASH)
LOWER CONTROL FIELD CONTROL MODULE
NCA WIRE
RED WIRE
RED/GRN WIRE
RED/VIO WIRE
SOLID STATE
Go to component -> Electronic accelerator/cruise/idle speed control circuit -> LOWER CONTROL FIELD CONTROL MODULE
Wiring diagram lower control field control module (2 of 3)
1 2 CAN-B H CAN-B L
2 1 CAN-B H CAN-B L
2 1 CAN-B L CAN-B H
3 4 CAN B H CAN B L
AUDIO GATEWAY CONTROL MODULE (LEFT SIDE OF TRUNK)
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
CAN B L CAN B H
CAN-B H CAN-B L
CENTRAL GATEWAY CONTROL MODULE (UNDER LEFT SIDE OF DASH)
DRIVER SIDE SAM CONTROL MODULE W/ FUSE/ RELAY MODULE (LEFT REAR OF ENGINE COMPT)
GRN WIRE
LEFT FRONT DOOR CONTROL MODULE (IN DRIVER'S DOOR)
LEFT REAR DOOR CONTROL MODULE (LEFT REAR DOOR)
LEFT VOLTAGE DISTRIBUTOR (CAN) CONNECTOR
LOWER CONTROL FIELD CONTROL MODULE
PASSENGER SIDE SAM CONTROL MODULE (UNDER RIGHT SIDE OF DASH)
PTS CONTROL MODULE (LEFT REAR OF TRUNK)
REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE (LEFT SIDE OF TRUNK)
RESTRAINT SYSTEMS CONTROL MODULE (FRONT OF CENTER CONTROL MODULE)
RIGHT FRONT DOOR CONTROL MODULE (RIGHT FRONT DOOR)
RIGHT REAR DOOR CONTROL MODULE (RIGHT REAR DOOR)
RIGHT VOLTAGE DISTRIBUTOR (CAN) CONNECTOR
UPPER CONTROL PANEL CONTROL MODULE
WSS CONTROL UNIT (WEIGHT SENSING SYSTEM) (UNDER RIGHT FRONT SEAT)
YEL WIRE
Go to component -> High/low bus circuit (2 of 2) -> LOWER CONTROL FIELD CONTROL MODULE
Wiring diagram lower control field control module (3 of 3)
1 2 CAN B L CAN B H
BLK WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
CAN B L CAN B H
CENTER INSTRUMENT PANEL PTS WARNING DISPLAY
CENTER LEFT FRONT PTS ULTRASONIC SENSOR
CENTER RIGHT FRONT PTS ULTRASONIC SENSOR
COMPUTER DATA LINES SYSTEM
FUSE 3
GRN/WHT WIRE
HOT AT ALL TIMES
INNER LEFT FRONT PTS ULTRASONIC SENSOR
INNER LEFT REAR PTS ULTRASONIC SENSOR
INNER RIGHT FRONT PTS ULTRASONIC SENSOR
INNER RIGHT REAR PTS ULTRASONIC SENSOR
LOWER CONTROL FIELD CONTROL MODULE
OUT RIGHT REAR PTS ULTRASONIC SENSOR
OUTER LEFT FRONT PTS ULTRASONIC SENSOR
OUTER LEFT REAR PTS ULTRASONIC SENSOR
OUTER RIGHT FRONT PTS ULTRASONIC SENSOR
PNK WIRE
PTS CONTROL MODULE (LEFT REAR OF TRUNK)
PTS OFF SWITCH
REAR PTS WARNING DISPLAY
REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE (LEFT SIDE OF TRUNK)
RED WIRE
VIO WIRE
W H (+) (+) SV
W H (-) (-) SV W H (DATA)
W V (DATA)
WHT/RED WIRE
WHT/YEL WIRE
YEL/RED WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Parktronic circuit -> LOWER CONTROL FIELD CONTROL MODULE
