Mercedes-Benz E-class W211/S211 facelift (2006-2009) data 30 Wiring diagrams
This page contains all the electrical diagrams for the component. data 30, in which he is found in the car Mercedes-Benz E-class W211/S211 facelift (2006-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram data 30 (1 of 3)
1 2 3 31 DATA 30
1 2 3 4 5 CAN-B L
1 2 8 9 10 11 COMPUTER DATA LINES SYSTEM CAN-B L CAN-B H
2 3 4 CAN-B L CAN-B H
AMBIENT LAMP
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN-B H 31 30
DATA 30
DOME LAMP ON/OFF SWITCH
DOOR CONTACT ON/OFF SWITCH
FRONT DOME LAMP
FUSE 79 (LOWER RIGHT FRONT OF TRUNK)
GRN WIRE
HOT AT ALL TIMES
INTERIOR REAR VIEW MIRROR UNIT
LEFT FRONT DOOR CONTACT SWITCH
LEFT FRONT VANITY MIRROR ILLUMINATION
LEFT FRONT VANITY MIRROR ILLUMINATION SWITCH
LEFT READING LAMP
LEFT READING LAMP SWITCH
LEFT REAR DOOR CONTACT SWITCH (LEFT "C" PILLAR)
LIGHT RING
NCA WIRE
OVERHEAD CONTROL PANEL CONTROL MODULE (IN OVERHEAD CONSOLE)
RAIN/LIGHT SENSOR (BEHIND TOP CENTER OF WINDSHIELD)
REAR DOME LAMP, SWITCH
REAR PREFUSE
REAR SAM CONTROL MODULE WITH FUSE/RELAY MODULE (LEFT SIDE OF TRUNK)
RED WIRE
RED/BLK WIRE
RIGHT FRONT DOOR CONTACT SWITCH
RIGHT FRONT VANITY MIRROR ILLUMINATION
RIGHT FRONT VANITY MIRROR ILLUMINATION SWITCH
RIGHT READING LAMP
RIGHT READING LAMP SWITCH
RIGHT REAR DOOR CONTACT SWITCH
TRUNK LID CONTACT SWITCH (CENTER REAR OF TRUNK LID)
W/ INTERIOR MOTION SENSOR, W/ PANORAMIC SLIDING ROOF
W/ REAR INTERIOR LAMP
WHT WIRE
Go to component -> Courtesy lamps circuit (1 of 3) -> DATA 30
Wiring diagram data 30 (2 of 3)
1 2 3 31 DATA 30
1 2 3 4 CAN-B L
AMBIENT LAMP
AUTOMATIC DIMMING MIRROR
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
CAN B H 31
COMPUTER DATA LINES SYSTEM
DATA 30
DOME LAMP ON, OFF SWITCH
DOOR CONTACT ON, OFF SWITCH
EMERGENCY CALL SYSTEM CONTROL UNIT (CENTER OF TRUNK)
FRONT DOME LAMP
FUSE 9 FUSE/RELAY MODULE (LEFT SIDE OF TRUNK)
GARAGE DOOR OPENER INDICATOR LAMP
GARAGE DOOR OPENER PUSHBUTTON 1
GARAGE DOOR OPENER PUSHBUTTON 2
GARAGE DOOR OPENER PUSHBUTTON 3
GARAGE DOOR OPENER TRANSMITTER UNIT
GARAGE DOOR OPENER TRANSMITTER UNIT (INTEGRAL TO INTERIOR REARVIEW MIRROR)
GRN WIRE
GRN/BRN WIRE
GRY/BLU WIRE
HANDS-FREE SYSTEM MICROPHONE GROUP
HOT AT ALL TIMES
IN-CAR TEMPERATURE SENSOR
IN-CAR TEMPERATURE SENSOR FAN MOTOR
INTERIOR REARVIEW MIRROR UNIT
LEFT FRONT READING LAMP SWITCH
LEFT READING LAMP
LIGHT RING
NCA WIRE
OVERHEAD CONTROL PANEL CONTROL MODULE (IN OVERHEAD CONSOLE)
POTENTIAL SPLITTER
POWER TOPS SYSTEM
RAIN/LIGHT SENSOR (BEHIND TOP CENTER OF
REAR DOME LAMP, SWITCH
REAR SAM CONTROL MODULE W/
RED/BLK WIRE
RIGHT FRONT READING LAMP SWITCH
RIGHT READING LAMP
ROOF SWITCH
SOS SWITCH
SOS/ATA (EDW) SWITCH GROUP
VIO WIRE
WHT WIRE
WINDSHIELD
YEL WIRE
YEL/RED WIRE
Go to component -> Overhead console circuit -> DATA 30
Wiring diagram data 30 (3 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
CENTER OVERHEAD PANEL CONTROL MODULE
DATA 30
FUSE W/ FUSE, RELAY MODULE (LEFT SIDE OF TRUNK)
GRN WIRE
HOT AT ALL TIMES
INTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM
LEFT REAR DOME LAMP
MOTOR
NCA WIRE
OVERHEAD CONTROL PANEL CONTROL MODULE (IN OVERHEAD CONSOLE)
REAR SAM CONTROL MODULE
RED/BLK WIRE
ROOF SWITCH
SENSOR
SENSOR SENSOR
SLIDING SUNROOF LINING SWITCH
TILTING/SLODING ROOF (SR (SHD)) DRIVE UNIT
VIO WIRE
W/ SR (SDH)
W/O SR (SDH)
YEL WIRE
Go to component -> Power top/sunroof circuit -> DATA 30
