Mercedes-Benz E-class W211/S211 (2002-2006) Rear wiper circuit, wagon

1 2 1 CAN-B L CAN-B H REAR WIPER SWITCH 2 3 4 CAN H CAN L BLK/GRY WIRE BRN WIRE BRN/RED WIRE BRN/YEL WIRE CAN B CAN L CAN-H COMPUTER DATA LINES SYSTEM FUSE 11 FUSE 7 GRN/VIO WIRE HOT AT ALL TIMES REAR PREFUSE BOX (LOWER RIGHT OF FRONT TRUNK) FUSE 80 ORG/ WIRE REAR DOOR CONTROL MODULE (RIGHT SIDE OF TAILGATE) REAR SAM CONTROL MODULE WITH FUSE, RELAY MODULE (LEFT SIDE OF TRUNK) REAR WIPER RELAY RED WIRE RELAY 2 ENERGIZED SOLID STATE TAILGATE WIPER MOTOR UPPER CONTROL PANEL CONTROL MODULE (BEHIND CENTER OF DASH) YEL WIRE
