Starting circuit for Mercedes-Benz E-class W211/S211 (2002-2006)
Starting circuit
AUXILIARY BATTERY RELAY (RIGHT REAR OF ENG COMPT)
BATTERY (RIGHT SIDE OF TRUNK)
BATTERY CONTROL MODULE (RIGHT REAR OF TRUNK)
BLK WIRE
BRN WIRE
BRN/RED WIRE
CHARGING CIRCUIT
CIRCUIT 57 RELAY
CIRCUIT 87 RELAY (ENGINE)
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (ME-SFI) (LEFT REAR OF ENG COMPT)
FRONT PREFUSE BOX (RIGHT FRONT FOOTWELL)
FUSE 59
FUSE 70
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
POWER DISTRIBUTION SYSTEM AUXILIARY BATTERY (RIGHT REAR OF ENG COMPT)
RED WIRE
SOLID STATE
STARTER
STARTER RELAY
VIO/WHT WIRE
