Mercedes-Benz E-class W210/S210 facelift (1999-2003) left front backrest fore/aft motor Wiring diagram

1 3 B+ GROUND 9 18 CAN L CAN H BACKREST FORE/AFT BLK WIRE BLU WIRE BRN WIRE BRN/RED WIRE COLUMN IN/OUT COLUMN UP/DOWN COMPUTER DATA LINES ELECTRIC STEERING COLUMN MOTOR FORE/AFT FRONT RAISE/LOWER FUSE 13 FUSE 16 FUSE 8 FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT) GRN WIRE GRY WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/WHT WIRE GRY/YEL WIRE HEAD RESTRAINT HOT AT ALL TIMES LEFT FRONT BACKREST FORE/AFT MOTOR LEFT FRONT DOOR CONTROL MODULE LEFT FRONT ELECTRONIC SEAT ADJUSTMENT CONTROL MODULE LEFT FRONT ELECTRONIC SEAT ADJUSTMENT SWITCH LEFT FRONT SEAT FORE/ AFT MOTOR LEFT FRONT SEAT FRONT RAISE/LOWER MOTOR LEFT FRONT SEAT REAR RAISE/LOWER MOTOR LEFT HEAD RESTRAINT RAISE/LOWER MOTOR MEMORY 1 MEMORY 2 MEMORY 3 MEMORY STORE REAR FUSE BOX (BELOW RIGHT REAR SEAT) REAR RAISE/LOWER RED WIRE RED/BLK WIRE RED/YEL/GRY WIRE RED/YEL/WHT WIRE STAR POINT COUPLER DATABUS CONNECTOR TELESCOPIC ADJUSTMENT MOTOR TILT ADJUSTMENT MOTOR VIO WIRE WHT WIRE WHT/BRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE
