Wiring diagram engine performance 3.2ls for Mercedes-Benz E-class W124/S124/C124/A124 (1992-1997)

ADJUSTABLE CAMSHAFT TIMING SOLENOID BATTERY BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE CAMSHAFT POSITION SENSOR CRANKSHAFT POSITION SENSOR EGR SWITCHOVER VALVE ENGINE CONTROL MODULE (IN RIGHT COMPONENT COMPARTMENT) ENGINE COOLANT TEMPERATURE SENSOR INTAKE AIR TEMPERATURE SENSOR GRN WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT FILM MASS AIR FLOW SENSOR HOT IN RUN OR START IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 INJ 3 INJ. #4 INJ. #2 INJ. #5 INJ. #1 INJ. #6 KNOCK SENSOR 1 (RIGHT SIDE OF ENGINE) KNOCK SENSOR 2 (LEFT SIDE OF ENGINE) NCA WIRE PNK WIRE PNK/RED WIRE RED WIRE RED/BLU WIRE RESONANCE INTAKE MANIFOLD SWITCHOVER VALVE SOLID STATE SPARK PLUG #1 SPARK PLUG #6 SPARK PLUG #2 SPARK PLUG #5 SPARK PLUG #3 SPARK PLUG #4 TERMINAL BLOCK VIO WIRE WHT WIRE YEL WIRE YEL/GRN WIRE YEL/WHT WIRE
