Instrument cluster circuit for Mercedes-Benz E-class AMG W210/S210 facelift (1999-2002)

"CHECK ENGINE" MIL 1 2 3 4 SCROLL FWD/ BACK BUTTON, SYSTEM SELECTION BUTTON 1 2 PNK WIRE ABS MIL IND AIR CONDITIONING SYSTEM BAS/ASR IND BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE FLUID LEVEL SWITCH (ON BRAKE FLUID RESERVOIR) BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM ECL SWITCH ECT GAUGE ELECTRONIC IGNITION LOCK CONTROL MODULE ELECTRONIC SPEEDO- METER ESP WARNING IND EXTERIOR LIGHTS SYSTEM AIR CONDITIONING SYSTEM EXTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM FUEL LEVEL GAUGE FUEL LEVEL SENSOR (IN FUEL TANK, AT FRONT BULKHEAD IN TRUNK) FUEL RESERVE IND FUSE 10 FUSE 4 FUSE 7 FUSE, RELAY BOX (ON LEFT REAR OF ENGINE COMPARTMENT) GRN WIRE GRN/BLU WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/VIO WIRE HIGH BEAM IND HORN HORN/ AIRBAG CLOCK SPRING CONTACT HOT AT ALL TIMES HOT IN OFF, ACC OR RUN HOT IN RUN OR START HYDRAULIC FLUID LEVEL SWITCH ILLUMINATION CONTROL MODULE (CANADA) INSTRUMENT CLUSTER INSTRUMENT ILLUMINATION (4 BULBS) INSTRUMENT, SEARCH ILLUMINATION PUSHBUTTON (BRIGHT) INSTRUMENT, SEARCH ILLUMINATION PUSHBUTTON (DARK) LCS SWITCH LEFT FRONT DOOR SWITCH LEFT FRONT SEAT BELT/ COMFORT SWITCH (IN DRIVER'S SEAT BELT BUCKLE) LEFT MULTIFUNCTION STEERING WHEEL PUSHBUTTON GROUP LEFT TURN SIGNAL INDICATOR LOW BRAKE FLUID LEVEL/ PARKING BRAKE INDICATOR LAMP MULTI-FUNCTION DISPLAY ILLUM MULTI-FUNCTION DISPLAY ILLUM (WHITE) NCA WIRE PNK/BLU WIRE PSE CONTROL MODULE (BELOW RIGHT REAR SEAT) RED WIRE RED/YEL WIRE RIGHT MULTIFUNCTION STEERING WHEEL PUSHBUTTON GROUP RIGHT TURN SIGNAL INDICATOR SEAT BELT REMINDER IND SOLID STATE SOUND SYSTEM/ NAVIGATION SYSTEM SPECIAL FUNCTIONS, VOLUME, ACCEPT/ TERMINATE PHONE CALL BUTTON SRS IND STARTING/CHARGING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM TACHO- METER TRIP ODO- METER RESET PUSHBUTTON VIO WIRE WARNING BUZZER WHT WIRE WHT/BLK WIRE WINDSHIELD WASHER FLUID LEVEL SWITCH (ON TOP OF WASHER FLUID RESERVOIR) YEL WIRE
