Anti-theft circuit for Mercedes-Benz E-class AMG W210/S210 facelift (1999-2002)

1 2 3 4 4 ATA 1 2 3 4 PWR GRND CTRL LOCK 1 2 CAN H CAN L 2 3 6 30 30 LK PWR 4 5 10 11 PWM A PWM B CAN L CAN H ALARM HORN (BEHIND RIGHT HEAD- LIGHT UNIT) RIGHT TAILLAMP UNIT ALARM SIREN (W/ AUXILIARY BATTERY) ANTI-LOCK BRAKES SYSTEM B+ GROUND B+ BLK WIRE BLK/VIO WIRE BLK/YEL WIRE BLK/YEL/RED WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/YEL WIRE CAN-H- CAN-L- COMPUTER DATA LINES SYSTEM ELECTRONIC IGNITION- STARTER SWITCH CONTROL MODULE (ON IGNITION SWITCH) ELECTRONIC STEERING COLUMN CONTROL MODULE FUSE 11 FUSE 19 FUSE 5 FUSE 9 FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT) GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/BLK/WHT WIRE GRY/RED WIRE GRY/RED/WHT WIRE HOOD HORN R TAIL HOT AT ALL TIMES ILLUMINATION CONTROL MODULE (BEHIND LEFT SIDE OF DASH) INSTRUMENT CLUSTER SYSTEM LED BLS LEFT FOOTWELL) LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH PNEUMATIC SYSTEM EQUIPMENT (PSE) CONTROL MODULE (BELOW RIGHT REAR SEAT) REAR FUSE BOX (BELOW RIGHT REAR SEAT) RED WIRE RED/GRN WIRE RED/WHT WIRE RF DOOR LR DOOR RR DOOR RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH SEDAN, LIMOUSINE SIREN STOP LAMP SUPRESSION RELAY MODULE (ANTI-LOCK BRAKES SYSTEM) STOP LAMP SWITCH TAILGATE CLOSING ASSIST MODULE TERMINAL BLOCK TRUNK LAMP TRUNK LF DOOR VIO WIRE W/ ELECTRONIC STABILITY W/O ELECTRONIC STABILITY WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE
