Heated seats circuit for Mercedes-Benz E-class AMG W210/S210 (1996-1999)
Heated seats circuit
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BRN WIRE
COCKPIT SWITCH
FRONT HEATED SEAT CONTROL MODULE
FUSE 12
FUSE AND RELAY BOX
GRY/BLU WIRE
HOT AT ALL TIMES
HOT IN ACC, RUN OR START
LEFT FRONT BACKREST HEATER ELEMENT LEFT FRONT SEAT CUSHION HEATER ELEMENT
REAR FUSE BOX FUSE 18
RED/GRN/GRY WIRE
RIGHT FRONT BACKREST HEATER ELEMENT
RIGHT FRONT SEAT CUSHION HEATER ELEMENT
