Warning system circuits, coupe & convertible for Mercedes-Benz E-class AMG W124/S124/C124/A124 (1994-1996)

BLK/RED WIRE BLK/RED/VIO WIRE BRN WIRE BRN/GRY WIRE BRN/GRY/RED WIRE BRN/YEL (OR BLU) WIRE CONVENIENCE RELAY DOME/READING LAMPS DRIVER'S SEAT BELT SWITCH (IN DRIVER'S SEAT BELT BUCKLE) EXTERIOR LAMP FAILURE MONITORING UNIT (FUSE/RELAY BOX) EXTERIOR LAMP SWITCH (PIN 4) FUSE FUSE 5 FUSE/ RELAY BOX FUSE 9 GRN WIRE GRN/BLK WIRE GRY/VIO WIRE HOT AT ALL TIMES HOT IN RUN OR START INSTRUMENT CLUSTER LEFT FRONT DOOR SWITCH NCA WIRE PASSIVE RESTRAINTS SYSTEM POWER SEATS SYSTEM RED/GRN WIRE RED/WHT WIRE RIGHT FRONT DOOR SWITCH SEAT BELT IND SEAT BELT WARNING RELAY WARNING BUZZER SWITCH (PART OF IGNITION SWITCH) WARNING MODULE (BEHIND RIGHT SIDE OF INSTRUMENT CLUSTER) YEL WIRE
