Mercedes-Benz CLS-class C257 (2017-2021) computer data lines system Wiring diagrams

??? ??? BLU WIRE BLU/WHT WIRE BRN WIRE CAN HMI H CAN HMI L CAN LR H CAN LR L COMPUTER DATA LINES SYSTEM DRIVER-SIDE FUSE, RELAY MODULE ELECTRONIC IGNITION SWITCH CONTROL UNIT FLEX-E BP PNK FLEX-E BM WIRE FULLY INTEGRATED TRANSMISSION CONTROL ELECTRIC CONTROLLER UNIT FUSE 10 FUSE 205 GRN WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER NCA WIRE P NOT RED WIRE RED/BLU WIRE RED/GRN WIRE SIG STEERING COLUMN MODULE CONTROL UNIT STEERING WHEEL DOWNSHIFT BUTTON STEERING WHEEL ELECTRONICS STEERING WHEEL UPSHIFT BUTTON VEHICLE INTERIOR PREFUSE BOX VIO WIRE VIO/WHT WIRE

??? ??? BRN WIRE BRN/RED WIRE CAN B H CAN B L COMPUTER DATA LINES SYSTEM DRIVER-SIDE FUSE, RELAY MODULE EC GND EC+ FRONT SAM CONTROL UNIT FUSE 203 FUSE 302 FUSE 305 FUSE 316 HOT AT ALL TIMES INSIDE REAR VIEW MIRROR LEFT FRONT DOOR CONTROL UNIT LEFT OUTSIDE MIRROR NCA WIRE OVERHEAD CONSOLE OVERHEAD CONTROL PANEL CONTROL UNIT PASSENGER-SIDE A-PILLAR FUSE BOX RAIN/LIGHT SENSOR W/ ADDITIONAL FUNCTIONS RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR CONTROL UNIT RIGHT OUTSIDE MIRROR SIG YEL WIRE

ALL-WHEEL DRIVE CONTROL UNIT BRN WIRE COMPUTER DATA LINES SYSTEM ENGINE FUSE, RELAY MODULE FLEX-E BP PNK FLEX-E BM WIRE FUSE 125 FUSE 450 GRN WIRE HOT AT ALL TIMES HOT W/ ENGINE COMPARTMENT TERMINAL 15 RELAY ENERGIZED PNK/RED WIRE REAR FUSE, RELAY MODULE RED WIRE RED/YEL WIRE

BRN WIRE BRN/RED WIRE BRN/YEL WIRE CAN B H CAN B L COMPUTER DATA LINES SYSTEM DRIVER-SIDE FUSE, RELAY MODULE DRIVER-SIDE POWER WINDOW, OUTSIDE MIRROR ADJUSTMENT SWITCH GROUP FOLD IN/OUT FOLD OUT/IN FUSE 203 FUSE 302 GRN WIRE HOT AT ALL TIMES LEFT FRONT DOOR CONTROL UNIT LEFT OUTSIDE MIRROR NCA WIRE OUTSIDE MIRROR FOLD-IN/FOLD-OUT SWITCH PASSENGER-SIDE A-PILLAR FUSE BOX RED WIRE RIGHT FRONT DOOR CONTROL UNIT RIGHT OUTSIDE MIRROR YEL/GRN WIRE

??? ??? BRN WIRE BRN/RED WIRE CAN B H CAN B L CAN LR H CAN LR L COMPUTER DATA LINES SYSTEM DRIVER-SIDE FUSE, RELAY MODULE ELECTRONIC IGNITION SWITCH CONTROL UNIT FLEX-E BP PNK FLEX-E BM WIRE FRONT SAM CONTROL UNIT FUSE 201 FUSE 205 GRN WIRE HORNS CONTACT PLATE HOT AT ALL TIMES LEFT FANFARE HORN NCA WIRE RED/BLU WIRE RED/WHT WIRE RIGHT FANFARE HORN SIG STEERING COLUMN MODULE CONTROL UNIT STEERING WHEEL ELECTRONICS YEL WIRE

AUDIO H AUDIO L+ BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE CAN HMI H CAN HMI L COMPUTER DATA LINES SYSTEM DRIVER-SIDE FUSE, RELAY MODULE FUSE 200 FUSE 206 FUSE 322 FUSE 4 GRN WIRE HEAD-UP DISPLAY (LEFT SIDE OF DASH) HOT AT ALL TIMES HSVL INSTRUMENT CLUSTER INSTRUMENT CLUSTER SPEAKER LEFT LOWER CONTROL PANEL LVDS H LVDS L LVSD H LVSD L MULTIPLE FUSE 2 NCA WIRE ORG/ WIRE PASSENGER-SIDE A-PILLAR FUSE BOX RED WIRE RED/WHT WIRE RED/YEL WIRE SHIELD SOUND SYSTEMS TRIM) VIO WIRE VIO/WHT WIRE WHT WIRE

??? ??? BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE CAN A H CAN A L COMPUTER DATA LINES SYSTEM DRIVER-SIDE FUSE, RELAY MODULE DRIVER-SIDE INSTRUMENT PANEL BUTTON GROUP FUSE 2 FUSE 209 FUSE 4 GRN/YEL WIRE HAZARD LIGHT HAZARD SIG HOT AT ALL TIMES LIN 1 MULTIPLE FUSE 2 MULTIPLE FUSE 3 ORG/ WIRE PASSENGER-SIDE A-PILLAR FUSE BOX RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RIGHT LOWER CONTROL PANEL UPPER CONTROL PANEL CONTROL UNIT WHT WIRE YEL WIRE

??? ??? BLK WIRE BRN WIRE BRN/BLK WIRE BRN/RED WIRE BRN/YEL WIRE CAN B H CAN B L COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM DRIVER-SIDE FUSE, RELAY MODULE DRIVER-SIDE POWER WINDOW, OUTSIDE MIRROR ADJUSTMENT SWITCH GROUP FUSE 203 FUSE 214 FUSE 301 FUSE 302 GRN WIRE GRN/RED WIRE HOT AT ALL TIMES LEFT FRONT DOOR CONTROL UNIT LEFT FRONT DOOR POWER WINDOW MOTOR LEFT FRONT POWER WINDOW SWITCH LEFT REAR POWER WINDOW SWITCH MOT GND/(+) PASSENGER-SIDE A-PILLAR FUSE BOX PASSENGER-SIDE POWER WINDOW SWITCH REAR SIDE WINDOW CHILD SAFETY LOCK SWITCH RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR CONTROL UNIT (IN RIGHT FRONT DOOR) RIGHT FRONT DOOR POWER WINDOW MOTOR RIGHT FRONT POWER WINDOW SWITCH RIGHT REAR POWER WINDOW SWITCH SIG SYSTEM WHT/GRN WIRE YEL/GRN WIRE

??? ??? BLK WIRE BLK/VIO WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE CAN B H CAN B L COMPUTER DATA LINES SYSTEM GRN WIRE LEFT REAR DOOR CONTROL UNIT LEFT REAR DOOR POWER WINDOW MOTOR LEFT REAR POWER WINDOW SWITCH MOT GND/(+) RED WIRE RED/BLU WIRE RED/YEL WIRE RIGHT REAR DOOR CONTROL UNIT RIGHT REAR DOOR POWER WINDOW MOTOR RIGHT REAR POWER WINDOW SWITCH SIG WHT/BLK WIRE WHT/GRN WIRE

AUDIO/COMAND CONTROL PANEL BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/RED WIRE CAN A H CAN A L CAN B L CAN-B H AAG COMPUTER DATA LINES SYSTEM FUSE 476 GND MOT GRN WIRE HOT AT ALL TIMES MOT GND/(+) MOT- MULTIPLE FUSE 2 NCA WIRE PASSENGER-SIDE A-PILLAR FUSE BOX REAR FUSE, RELAY MODULE REAR SAM CONTROL UNIT REAR WINDOW ROLLER SUN BLIND MOTOR RED/BLK WIRE RED/BLU WIRE RIGHT LOWER CONTROL PANEL SENS SENS 1 SENS 2 SENS GND WHT WIRE YEL WIRE
