Mercedes-Benz CLS-class AMG C257 facelift (2021-2024) vio/wht Wiring diagrams

BLU WIRE BLU/WHT WIRE BRN WIRE CAN HMI H CAN HMI L CAN LR H CAN LR L COMPUTER DATA LINES SYSTEM DRIVER-SIDE FUSE, RELAY MODULE ELECTRONIC IGNITION SWITCH CONTROL UNIT FLEX-E BP PNK FLEX-E BM WIRE FULLY INTEGRATED TRANSMISSION CONTROL ELECTRIC CONTROLLER UNIT FUSE 10 FUSE 205 GRN WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER NCA WIRE P NOT RED WIRE RED/BLU WIRE RED/GRN WIRE SIG STEERING COLUMN MODULE CONTROL UNIT STEERING WHEEL DOWNSHIFT BUTTON STEERING WHEEL ELECTRONICS STEERING WHEEL UPSHIFT BUTTON VEHICLE INTERIOR PREFUSE BOX VIO WIRE VIO/WHT WIRE

BLK WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE CAN H H CAN H L CAN PER H CAN PER L COMPUTER DATA LINES SYSTEM DRIVER-SIDE FUSE, RELAY MODULE ELECTRONIC IGNITION SWITCH CONTROL UNIT ELECTRONIC STABILITY PROGRAM CONTROL UNIT FLEX-E BM FLEX-E BP FLEX-E BP PNK FLEX-E BM WIRE FUSE 205 FUSE 311 FUSE 415 FUSE 6 GRN WIRE GRN/ORG WIRE GRN/PNK WIRE GRN/WHT WIRE GRY/GRN WIRE HOT AT ALL TIMES INTELLIGENT DRIVE CONTROL UNIT (LEFT SIDE OF LUGGAGE COMPT) LEFT OUTER FRONT BUMPER RADAR SENSOR ME-SFI (ME) CONTROL UNIT MOT- MULTIPLE FUSE 1 PASSENGER-SIDE A-PILLAR FUSE BOX PNK WIRE REAR FUSE, RELAY MODULE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RIGHT OUTER FRONT BUMPER RADAR SENSOR SENS (+) SENS 2 SENS 1 SENS GND STEERING COLUMN MODULE CONTROL UNIT STOP LAMP SWITCH THROTTLE VALVE ACTUATOR VIO WIRE VIO/WHT WIRE YEL/BLU WIRE

ACCELERATOR PEDAL SENSOR ACTIVE BRAKE ASSIST CONTROLLER UNIT BLK WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE CAN B H CAN B L CAN HMI H CAN HMI L CAN PER H CAN PER L COMPUTER DATA LINES SYSTEM DISTRONIC DISTANCE-PILOT CONTROLLER UNIT DRIVETRAIN CONTROL UNIT FLEX-E BM FLEX-E BP GRN WIRE GRN/WHT WIRE HECKD INSTRUMENT CLUSTER LEFT OUTER REAR BUMPER RADAR SENSOR PNK WIRE RADOME HEATER REAR SAM CONTROL UNIT RED/BLK WIRE RED/BLU WIRE RIGHT OUTER REAR BUMPER RADAR SENSOR SENS 1 (+) SENS 1 SENS 1 GND SENS 2 SENS 2 (+) SENS 2 GND SHORT, LONG-RANGE RADAR SENSOR SIG VIO WIRE VIO/WHT WIRE WHT WIRE WHT/YEL WIRE YEL WIRE

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CAN B H CAN B L COMPUTER DATA LINES SYSTEM DRIVER SEAT BACKREST INCLINATION ADJUSTMENT MOTOR DRIVER SEAT CONTROL UNIT DRIVER SEAT CUSHION LENGTH ADJUSTMENT MOTOR DRIVER SEAT FORE/AFT ADJUSTMENT MOTOR DRIVER SEAT HEAD RESTRAINT ADJUSTMENT MOTOR DRIVER SEAT HEIGHT ADJUSTMENT MOTOR DRIVER SEAT INCLINATION ADJUSTMENT MOTOR DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT CONTROL UNIT DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER SEAT LUMBAR SUPPORT PNEUMATIC PUMP DRIVER-SIDE FUSE, RELAY MODULE FLEX-E BP FLEX-E BM PNK WIRE FUSE 203 FUSE 211 FUSE 303 FUSE 4 GRN WIRE GRN/VIO WIRE HOT AT ALL TIMES LEFT FRONT DOOR CONTROL UNIT LEFT FRONT SEAT ADJUSTMENT SWITCH GROUP MOT GND/(+) MOT GND/(+) TEMP MULTIPLE FUSE 1 NCA WIRE PASSENGER-SIDE A-PILLAR FUSE BOX PUMP (+) 31 RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE SEATS SYSTEM SENS SENS GND SIG SIG GND STEERING COLUMN MEMORY CIRCUIT STEERING COLUMN MODULE CONTROL UNIT TEMP VIO WIRE VIO/WHT WIRE VIO/YEL WIRE W/ CLIMATE CONTROL WHT WIRE WHT/BLK WIRE YEL WIRE

BRN WIRE CAN HMI H CAN HMI L COMPUTER DATA LINES SYSTEM DRIVER-SIDE FUSE, RELAY MODULE FUSE 213 FUSE 310 HOT AT ALL TIMES LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR PASSENGER-SIDE A-PILLAR FUSE BOX RED/BLK WIRE RED/GRN WIRE RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR VIO WIRE VIO/WHT WIRE

BLK WIRE BLK/BLU WIRE BLK/VIO WIRE BLU WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CAN B H CAN B L CAN B L CAN B H COMPUTER DATA LINES SYSTEM DRIVER-SIDE FUSE, RELAY MODULE FLEX-E BM FLEX-E BP FRONT PASSENGER SEAT BACKREST INCLINATION ADJUSTMENT MOTOR FRONT PASSENGER SEAT CONTROL UNIT FRONT PASSENGER SEAT CUSHION LENGTH ADJUSTMENT MOTOR FRONT PASSENGER SEAT FORE/ AFT ADJUSTMENT MOTOR FRONT PASSENGER SEAT HEAD RESTRAINT ADJUSTMENT MOTOR FRONT PASSENGER SEAT HEIGHT ADJUSTMENT MOTOR FRONT PASSENGER SEAT INCLINATION ADJUSTMENT MOTOR FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT CONTROL UNIT FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH FRONT PASSENGER SEAT LUMBAR SUPPORT PNEUMATIC PUMP FUSE 211 FUSE 302 FUSE 304 FUSE 5 GRN WIRE GRN/VIO WIRE HOT AT ALL TIMES MOT GND/(+) MOT GND/(+) TEMP MULTIPLE FUSE 1 NCA WIRE PASSENGER-SIDE A-PILLAR FUSE BOX PNK WIRE PUMP SIG RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR CONTROL UNIT RIGHT FRONT SEAT ADJUSTMENT SWITCH GROUP SEATS SYSTEM SENS SENS GND SIG SIG GND STEERING COLUMN MODULE CONTROL UNIT TEMP VIO WIRE VIO/WHT WIRE VIO/YEL WIRE W/ CLIMATE CONTROL WHT WIRE WHT/BLK WIRE YEL WIRE

AUDIO H AUDIO L+ BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE CAN HMI H CAN HMI L COMPUTER DATA LINES SYSTEM FUSE 322 FUSE 4 GRN WIRE HEAD-UP DISPLAY (LEFT SIDE OF DASH) HOT AT ALL TIMES HSVL INSTRUMENT CLUSTER INSTRUMENT CLUSTER SPEAKER LVDS H LVDS L MULTIPLE FUSE 2 NCA WIRE ORG/ WIRE PASSENGER-SIDE A-PILLAR FUSE BOX RED WIRE RED/WHT WIRE SHIELD SOUND SYSTEMS TRIM) VIO WIRE VIO/WHT WIRE

ANALOG CLOCK BLK WIRE BLU WIRE BLU/WHT WIRE BRAKE FLUID LEVEL SWITCH BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE CAN B H CAN B L CAN H H CAN H L COMPUTER DATA LINES SYSTEM COOLANT LEVEL SWITCH DRIVER-SIDE FUSE, RELAY MODULE ELECTRIC PARKING BRAKE SWITCH ELECTRONIC STABILITY PROGRAM CONTROL UNIT FRONT SAM CONTROL UNIT FUEL PRESSURE SENSOR FUEL PUMP CONTROL UNIT FUSE 200 FUSE 206 GRN WIRE GRN/GRY WIRE GRN/PNK WIRE GRN/YEL WIRE GRY/BLU WIRE HAZARD LIGHT COC HAZARD SIG HOT W/ BATTERY DISCONNECT SWITCH RELAY ENERGIZED LEFT FUEL TANK FUEL LEVEL INDICATOR FILL LEVEL SENSOR LIN 1 LIN 1 COC NCA WIRE ORG/ WIRE OUTSIDE TEMPERATURE SENSOR RED WIRE RED/YEL WIRE RIGHT FUEL TANK FUEL LEVEL INDICATOR FILL LEVEL SENSOR SIG SIG (1) SIG (2) SIG 3 SIG 4 SIG GND VIO WIRE VIO/WHT WIRE WHT WIRE YEL WIRE

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/YEL WIRE BLU/YEL WIRE BRN WIRE BRN/YEL WIRE CAN H H CAN H L COMPUTER DATA LINES SYSTEM CRASH DRIVER BELT FORCE LIMITER DRIVER ETR (GUS) SQUIB DRIVER SEAT SIDE PRE-SAFE PULSE SQUIB FRONT PASSENGER BELT FORCE LIMITER FRONT PASSENGER SEAT SIDE PRE-SAFE PULSE SQUIB FRONT PASSENGER SIDE BAG SQUIB GRN WIRE GRY WIRE GRY/YEL WIRE LEFT SIDE BAG SENSOR ME-SFI (ME) CONTROL UNIT NCA WIRE PNK/BLK WIRE PNK/YEL WIRE PYROFUSE (RIGHT SIDE OF DASH) RED/YEL WIRE RIGHT ACTIVE ENGINE HOOD SQUIB SIG SIG (+) SIG GND SIG GND SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT VIO WIRE VIO/WHT WIRE VIO/YEL WIRE

BLK WIRE BLK/GRY WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CAN HMI H CAN HMI L COMPUTER DATA LINES SYSTEM DRIVER BELT ANCHOR FITTING TENSIONER SQUIB DRIVER SEAT POSITION DETECTION SWITCH FRONT PASSENGER SEAT BELT BUCKLE SWITCH FRONT PASSENGER SEAT POSITION DETECTION SWITCH FUSE 312 GRN WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER LEFT ACTIVE ENGINE HOOD SQUIB LEFT FRONT BUMPER PEDESTRIAN PROTECTION SENSOR NCA WIRE ORG/GRN WIRE ORG/VIO WIRE PASSENGER-SIDE A-PILLAR FUSE BOX RED WIRE RED/BLU WIRE RED/GRY WIRE RIGHT FRONT BUMPER PEDESTRIAN PROTECTION SENSOR RIGHT FRONT DOOR PRESSURE SENSOR RIGHT REAR EMERGENCY TENSIONING RETRACTOR SQUIB RIGHT REAR SIDE BAG SQUIB SIG SIG GND SIG SIG SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT VIO WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE YEL WIRE
