Mercedes-Benz CLS-class AMG C257 facelift (2021-2024) telephone control unit Wiring diagrams
This page contains all the electrical diagrams for the component. telephone control unit, in which he is found in the car Mercedes-Benz CLS-class AMG C257 facelift (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram telephone control unit (1 of 3)
AC HOUSING,
ALL-WHEEL DRIVE CONTROL UNIT
ANALOG CLOCK
BRN WIRE
CLIMATE CONTROL OPERATING UNIT
CLIMATE CONTROL UNIT
DRIVER SEAT CONTROL UNIT
DRIVER SEAT HEATER CONTROL UNIT
DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT CONTROL UNIT
DRIVER SEAT LUMBAR SUPPORT PNEUMATIC PUMP
DRIVER SEAT REAR SEAT ENTERTAINMENT SYSTEM ELECTRICAL CONNECTOR
DRIVER SEAT SIDE PRE-SAFE PULSE SQUIB
DRIVER SIDE BAG SQUIB
EXTERNAL CD DRIVE
FRONT PASSENGER FOOTWELL SOCKET
FRONT PASSENGER SEAT CONTROL UNIT
FRONT PASSENGER SEAT HEATER CONTROL UNIT
FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT CONTROL UNIT
FRONT PASSENGER SEAT LUMBAR SUPPORT PNEUMATIC PUMP
FRONT PASSENGER SEAT PARTIALLY ELECTRIC SEAT ADJUSTMENT SWITCH
FRONT PASSENGER SEAT REAR SEAT ENTERTAINMENT SYSTEM ELECTRICAL CONNECTOR
FRONT PASSENGER SEAT SIDE PRE-SAFE PULSE SQUIB
FRONT PASSENGER SIDE AIR VENT AMBIANCE ILLUMINATION
FRONT PASSENGER SIDE BAG SQUIB
FRONT SEAT HEATER/ SEAT VENTILATION CONTROL UNIT
GLOVE BOX LAMP/ SWITCH
LEFT FRONT CENTER CONSOLE AMBIANCE ILLUMINATION
RIGHT FRONT FOOTWELL LAMP
RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
RIGHT REAR DOOR CONTROL UNIT
SEPARATE TRUNK LID LOCK SWITCH
TELEPHONE CONTROL UNIT
UPPER CONTROL PANEL CONTROL UNIT
Go to component -> Ground distribution circuit (6 of 8) -> TELEPHONE CONTROL UNIT
Wiring diagram telephone control unit (2 of 3)
ADAPTIVE DAMPING SYSTEM CONTROL UNIT
AIR BODY CONTROL PLUS CONTROL UNIT
AIR BODY CONTROL UNIT
AUDIO/COMAND CONTROL PANEL
AUDIO/COMAND DISPLAY
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/RED WIRE
CAN A H
CAN A L
FLEX-E BM
FLEX-E BP
GRN WIRE
GRN/WHT WIRE
MOBILE PHONE CRADLE CONTROL UNIT
PARKING SYSTEM CONTROL UNIT
PNK WIRE
REAR PASSENGER COMPARTMENT MOBILE PHONE CRADLE CONTROL UNIT
TELEMATICS CAN (CAN A) POTENTIAL DISTRIBUTOR
TELEPHONE CONTROL UNIT
TOUCHPAD (IF EQUIPPED)
W/ DESIGN REAR INDIVIDUAL SEATS
W/ PARKING PILOT
W/ TOUCHPAD ONLY
Go to component -> High/low bus circuit (4 of 6) -> TELEPHONE CONTROL UNIT
Wiring diagram telephone control unit (3 of 3)
ALARM SIREN
AUDIO/COMAND CONTROL PANEL
DIAGNOSTIC CONNECTOR
DRIVER-SIDE INSTRUMENT PANEL BUTTON GROUP
DRIVETRAIN CONTROL UNIT
FM, AM, CL, DAB, KEYLESS-GO ANTENNA AMPLIFIER
FROM ENGINE COMPARTMENT PREFUSE BOX (DIAGRAM 1 OF 8)
FROM MULTIPLE FUSE 1 (DIAGRAM 5 OF 8)
FUSE 1
FUSE 2
FUSE 3
FUSE 308
FUSE 309
FUSE 311
FUSE 312
FUSE 313
FUSE 318
FUSE 319
FUSE 320
FUSE 321
FUSE 322
FUSE 4
FUSE 5
FUSE 6
HEAD-UP DISPLAY
INSTRUMENT CLUSTER
KEYLESS-GO CONTROL UNIT
ME-SFI (ME) CONTROL UNIT
MULTIMEDIA CONNECTION UNIT
MULTIPLE FUSE 2
MULTIPLE FUSE 3
NCA WIRE
PERFUME ATOMIZER GENERATOR
REAR AIR CONDITIONING OPERATING UNIT
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
SLIDING ROOF CONTROL MODULE
SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT
TELEPHONE CONTROL UNIT
THEFT DETECTION SYSTEM ELECTRICAL CONNECTOR
TO ELECTRONIC IGNITION SWITCH CONTROL UNIT (DIAGRAM 4 OF 8)
TOUCHPAD (IF EQUIPPED)
W/ AIR QUALITY PACKAGE
W/ INTERIOR MONITORING
Go to component -> Power distribution circuit (8 of 8) -> TELEPHONE CONTROL UNIT
