Mercedes-Benz CLS-class AMG C257 facelift (2021-2024) tank cap central locking actuator Wiring diagram
This page shows the only wiring diagram for the component.tank cap central locking actuator, which is found in the car Mercedes-Benz CLS-class AMG C257 facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tank cap central locking actuator (1 of 1)
ACTIVE BRAKE ASSIST CONTROLLER UNIT
AIR BODY CONTROL COMPRESSOR
BACKUP RELAY
BATTERY DISCONNECT SWITCH RELAY
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CPC RELAY
DC/AC CONVERTER CONTROL UNIT
DC/DC CONVERTER CONTROL UNIT
DISTRONIC DISTANCE-PILOT CONTROLLER UNIT
ENGINE FUSE, RELAY MODULE
HEATED REAR WINDOW RELAY
KEYLESS-GO CONTROL UNIT
LEFT FANFARE HORN
LEFT FRONT LAMP UNIT
LEFT OUTER FRONT BUMPER RADAR SENSOR
LEFT REAR LAMP UNIT
LOW TEMPERATURE CIRCUIT CIRCULATION PUMP 2
LUGGAGE COMPARTMENT SOCKET
NCA WIRE
PASSENGER SIDE ENGINE HOOD CONTACT SWITCH
RADOME HEATER
REAR FUSE, RELAY MODULE
RIGHT FANFARE HORN
RIGHT FRONT BRAKE WEAR SENSOR
RIGHT OUTER FRONT BUMPER RADAR SENSOR
SHORT, LONG-RANGE RADAR SENSOR
SPRAY NOZZLE HOSE HEATER
TANK CAP CENTRAL LOCKING ACTUATOR
TRAILER RECOGNITION CONTROL UNIT
TRAILER SOCKET
TRUNK LID/ LIFTGATE LOCK
TV TUNER CONTROL UNIT
W/ ACTIVE DISTANCE ASSIST DISTRONIC
W/O ACTIVE DISTANCE ASSIST DISTRONIC
WINDSHIELD WASHER SYSTEM PUMP
WIPER MOTOR
Go to component -> Ground distribution circuit (1 of 8) -> TANK CAP CENTRAL LOCKING ACTUATOR
