Mercedes-Benz CLS-class AMG C257 facelift (2021-2024) pnk Wiring diagrams

This page contains all the electrical diagrams for the component. pnk, in which he is found in the car Mercedes-Benz CLS-class AMG C257 facelift (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

pnk wiring diagram (31 of 50)

ADVANCED SOUND SYSTEM AMPLIFIER CONTROL UNIT BLU WIRE BRN WIRE CENTER INSTRUMENT PANEL MIDRANGE SPEAKER CENTER INSTRUMENT PANEL SPEAKER DRIVER HANDS-FREE SYSTEM MICROPHONE FRONT PASSENGER HANDS-FREE SYSTEM MICROPHONE GRN WIRE GRY WIRE GRY/BLK WIRE MUTE NCA WIRE ORG/ WIRE PNK WIRE REAR PASSENGER COMPARTMENT MULTIMEDIA CONNECTION RED WIRE RED/BLK WIRE RED/GRN WIRE RED/WHT WIRE SHIELD SOUND AMPLIFIER CIRCUIT SOUND SYSTEM AMPLIFIER CONTROL UNIT SOUND SYSTEM MIDLINE AMPLIFIER CONTROL UNIT SOUND SYSTEMS UPPER CONTROL PANEL CONTROL UNIT USB USB GND USB H USB L VIO WIRE W/ ADVANCED SOUND SYSTEM W/O ADVANCED SOUND SYSTEM WHT WIRE

Go to component -> Comand actuation circuit (3 of 7) -> PNK WIRE

pnk wiring diagram (32 of 50)

BLK WIRE BLK/WHT WIRE BLU WIRE BLU/PNK WIRE BLU/VIO WIRE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE CAN A H CAN A L CAN HMI H CAN HMI L COMPUTER DATA LINES SYSTEM DIAG DIAGNOSTIC CONNECTOR DIGITAL INSTRUMENT CLUSTER FULL DISPLAY FAN MOTOR DRIVER-SIDE FUSE, RELAY MODULE ETH (+) WAKE UP ETH (-) FM AM FUSE 206 FUSE 3 GPS GPS ANTENNA GRN WIRE HEAD UNIT HOT AT ALL TIMES HSVL MULTIPLE FUSE 3 NAVIGATION SYSTEM NCA WIRE ORG/ WIRE PASSENGER-SIDE A-PILLAR FUSE BOX PNK WIRE RED WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RVC SDARS SDARS ANTENNA SHIELD SHIELD AUX/RVC SHIELD GPS SIG TOUCHPAD VIO WIRE VIO/WHT WIRE W/ COMAND APS W/O COMAND APS WHT/BLK WIRE

Go to component -> Comand actuation circuit (7 of 7) -> PNK WIRE

pnk wiring diagram (33 of 50)

BRN WIRE CAN HMI H CAN HMI L COMPUTER DATA LINES SYSTEM ELECTRIC POWER STEERING ACTUATOR MOTOR ELECTRIC POWER STEERING TORQUE SENSOR ELECTRICAL POWER STEERING CONTROL UNIT ENGINE COMPARTMENT PREFUSE BOX FLEX-E BM FLEX-E BP FUSE 8 GRN WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER NCA WIRE PNK WIRE RED WIRE SENS 1 SENS 1 GND SENS 2 SENS 2 GND SIG VIO WIRE VIO/WHT WIRE

Go to component -> Electronic power steering circuit -> PNK WIRE

pnk wiring diagram (34 of 50)

BACKUP CAMERA CONTROL UNIT (IF EQUIPPED) (CENTER REAR OF TRUNK LID) BLK WIRE BLK/WHT WIRE BRN WIRE CAN A H CAN A L CAN HMI H CAN HMI L ELECTRICAL POWER STEERING CONTROL UNIT FLEX-E BM FLEX-E BP GRN WIRE HEAD UNIT (W/ COMAND ACTUATION) HEAD-UP DISPLAY (IF EQUIPPED) (LEFT SIDE OF DASH) INSTRUMENT CLUSTER INTELLIGENT DRIVE CONTROL UNIT LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR PNK WIRE RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR STEREO MULTI-FUNCTION CAMERA SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT (BELOW CENTER OF DASH) USER INTERFACE CAN (CAN HMI) POTENTIAL DISTRIBUTOR VIO WIRE VIO/WHT WIRE

Go to component -> High/low bus circuit (1 of 6) -> PNK WIRE

pnk wiring diagram (35 of 50)

ACTIVE BRAKE ASSIST CONTROLLER UNIT ALL-WHEEL DRIVE CONTROL UNIT BLK WIRE BLK/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE CAN B H CAN B L CAN H H CAN H L CAN HMI H CAN HMI L CAN PER H CAN PER L CAN-H L PNK FLEX-E BM WIRE CAN-HMI H PNK FLEX E BM WIRE DRIVE UNIT CONTROL UNIT (RIGHT FRONT FOOTWELL) ELECTRONIC IGNITION SWITCH CONTROL UNIT ELECTRONIC STABILITY PROGRAM CONTROL UNIT FLEX-E BM FLEX-E BP FLEX-E BP PNK FLEX-E BM PNK FLEX-E BM WIRE FLEX-E BP PNK FLEX-E BM WIRE GRN WIRE GRN/WHT WIRE LEFT FRONT LAMP UNIT MONO MULTI-FUNCTION CAMERA (IF EQUIPPED) (TOP CENTER OF WINDSHIELD) PERIPHERY CAN (CAN PER) POTENTIAL DISTRIBUTOR PNK FLEX-E BM WIRE PNK WIRE RIGHT FRONT LAMP UNIT RIGHT OUTER REAR BUMPER INTEGRATED RADAR SENSOR STEERING COLUMN MODULE CONTROL UNIT (TOP OF STEERING COLUMN) SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT VIO WIRE VIO/WHT WIRE W/ DISTRONIC PLUS

Go to component -> High/low bus circuit (2 of 6) -> PNK WIRE

pnk wiring diagram (36 of 50)

ADAPTIVE DAMPING SYSTEM CONTROL UNIT AIR BODY CONTROL PLUS CONTROL UNIT AIR BODY CONTROL UNIT AUDIO/COMAND CONTROL PANEL AUDIO/COMAND DISPLAY BLK WIRE BLK/WHT WIRE BRN WIRE BRN/RED WIRE CAN A H CAN A L FLEX-E BM FLEX-E BP GRN WIRE GRN/WHT WIRE MOBILE PHONE CRADLE CONTROL UNIT PARKING SYSTEM CONTROL UNIT PNK WIRE REAR PASSENGER COMPARTMENT MOBILE PHONE CRADLE CONTROL UNIT TELEMATICS CAN (CAN A) POTENTIAL DISTRIBUTOR TELEPHONE CONTROL UNIT TOUCHPAD (IF EQUIPPED) W/ DESIGN REAR INDIVIDUAL SEATS W/ PARKING PILOT W/ TOUCHPAD ONLY

Go to component -> High/low bus circuit (4 of 6) -> PNK WIRE

pnk wiring diagram (37 of 50)

ADVANCED SOUND SYSTEM AMPLIFIER CONTROL UNIT AIR BODY CONTROL, DISTRONIC PLUS BLK WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE CAN A H CAN A L CAN C H CAN C L CAN L H CAN L L CAN PER H CAN PER L DRIVETRAIN CONTROL UNIT (RIGHT FRONT FOOTWELL) ENGINE SOUND CONTROL UNIT (LEFT SIDE OF LUGGAGE COMPT) FLEX-E BM FLEX-E BP FUEL PUMP CONTROL UNIT (UNDER RIGHT REAR SEAT) FULLY INTEGRATED TRANSMISSION CONTROL ELECTRIC CONTROLLER UNIT GRN WIRE GRN/WHT WIRE HYBRID-CAN (CAN L) POTENTIAL DISTRIBUTION ME-SFI (ME) CONTROL UNIT (LEFT TOP OF ENGINE) ORG/ WIRE ORG/WHT WIRE PNK WIRE SOUND SYSTEM AMPLIFIER CONTROL UNIT SOUND SYSTEM MIDLINE AMPLIFIER CONTROL UNIT STARTER GENERATOR CONTROL UNIT

Go to component -> High/low bus circuit (5 of 6) -> PNK WIRE

pnk wiring diagram (38 of 50)

BLK/YEL WIRE BLU WIRE BRN WIRE CAN LR H CAN LR L COMPUTER DATA LINES SYSTEM DRIVER-SIDE FUSE, RELAY MODULE FLEX-E BM FLEX-E BP FUSE 205 FUSE 211 GRN WIRE GRY WIRE HEAD UNIT MULTI-FUNCTION STEERING WHEEL BUTTON GROUP HORNS CONTACT PLATE HOT AT ALL TIMES INSTRUMENT CLUSTER MULTI-FUNCTION STEERING WHEEL BUTTON GROUP NCA WIRE PNK WIRE RED WIRE RED/BLU WIRE RES+ SENS GND SIG SIG GND SPI CLK SPI MISO SPI MOSI STEERING COLUMN MODULE CONTROL UNIT (TOP OF STEERING COLUMN) STEERING WHEEL DOWNSHIFT BUTTON STEERING WHEEL ELECTRONICS STEERING WHEEL HEATER STEERING WHEEL UPSHIFT BUTTON SUPPLEMENTAL RESTRAINTS SYSTEM TEMP VIO/YEL WIRE

Go to component -> Power steering column circuit -> PNK WIRE

pnk wiring diagram (39 of 50)

AUDIO H AUDIO L+ BLK WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/WHT WIRE COMAND ACTUATION CIRCUIT FUSE 475 GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES LEFT FRONT ACTIVE ENGINE NOISE COMPENSATION MICROPHONE LEFT FRONT DOOR MIDRANGE SPEAKER LEFT FRONT DOOR TWEETER LEFT FRONT FOOTWELL WOOFER LEFT REAR DOOR MIDRANGE SPEAKER LEFT REAR DOOR TWEETER LEFT REAR SURROUND SOUND SYSTEM MIDRANGE SPEAKER MIC H MIC-L MOST MOST DATA BUS CIRCUIT MUTE NCA WIRE PNK WIRE PNK/BLK WIRE REAR FUSE, RELAY MODULE RED WIRE RIGHT FRONT ACTIVE ENGINE NOISE COMPENSATION MICROPHONE SHIELD SOUND SYSTEM AMPLIFIER CONTROL UNIT VIO WIRE VIO/BLK WIRE WAKEUP WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE

Go to component -> Sound amplifier circuit, w/o uprated engine & advanced sound system (1 of 2) -> PNK WIRE

pnk wiring diagram (40 of 50)

AUDIO H AUDIO L+ BLK WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE COMAND ACTUATION CIRCUIT COMPUTER DATA LINES SYSTEM FUSE 475 GRN WIRE GRN/BLK WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES LEFT FRONT ACTIVE ENGINE NOISE COMPENSATION MICROPHONE LEFT FRONT DOOR MIDRANGE SPEAKER LEFT FRONT DOOR TWEETER LEFT FRONT FOOTWELL WOOFER LEFT REAR DOOR MIDRANGE SPEAKER MIC H MIC-L MOST MOST DATA BUS CIRCUIT MUTE NCA WIRE PNK WIRE PNK/BLK WIRE REAR FUSE, RELAY MODULE RED WIRE RIGHT FRONT ACTIVE ENGINE NOISE COMPENSATION MICROPHONE SHIELD SOUND SYSTEM MIDLINE AMPLIFIER CONTROL UNIT VIO WIRE VIO/BLK WIRE WAKEUP WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Sound amplifier circuit, w/ uprated engine (1 of 2) -> PNK WIRE

Page 4 of 5
