Mercedes-Benz CLS-class AMG C257 facelift (2021-2024) outside mirror adjustment switch Wiring diagram
This page shows the only wiring diagram for the component.outside mirror adjustment switch, which is found in the car Mercedes-Benz CLS-class AMG C257 facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram outside mirror adjustment switch (1 of 1)
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
BSM (+) SENS 1
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
DRIVER-SIDE FUSE, RELAY MODULE
DRIVER-SIDE POWER WINDOW, OUTSIDE MIRROR ADJUSTMENT SWITCH GROUP
EC (+) EC GND
FLEX-E BM
FLEX-E BP
FOLD OUT/IN
FUSE 203
FUSE 211
FUSE 302
GRN WIRE
HEAT (+) BSM GND
HEAT GND
HOT AT ALL TIMES
ILLU (+) FOLD IN/OUT
LEFT FRONT DOOR CONTROL UNIT (IN LEFT FRONT DOOR)
LEFT FRONT SEAT ADJUSTMENT SWITCH GROUP
LEFT OUTSIDE MIRROR
LEFT OUTSIDE MIRROR ADJUSTMENT SWITCH
MOT GND/(+)
MOT LR (+)/GND
MOT UD (+)/GND
NCA WIRE
OUTSIDE MIRROR ADJUSTMENT SWITCH
OUTSIDE MIRROR FOLD-IN/FOLD-OUT SWITCH
PASSENGER-SIDE A-PILLAR FUSE BOX
PNK WIRE
RED WIRE
RED/WHT WIRE
RIGHT FRONT DOOR CONTROL UNIT
RIGHT FRONT SEAT ADJUSTMENT SWITCH GROUP
RIGHT OUTSIDE MIRROR
RIGHT OUTSIDE MIRROR ADJUSTMENT SWITCH
SENS
SENS 2
SENS GND
SIG GND
STEERING COLUMN MODULE CONTROL UNIT (TOP OF STEERING COLUMN)
VIO WIRE
W/ CLIMATE CONTROL
YEL/GRN WIRE
Go to component -> Memory mirrors circuit -> OUTSIDE MIRROR ADJUSTMENT SWITCH
