Mercedes-Benz CLS-class AMG C257 facelift (2021-2024) central air distribution position detection microswitch Wiring diagram
This page shows the only wiring diagram for the component.central air distribution position detection microswitch, which is found in the car Mercedes-Benz CLS-class AMG C257 facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram central air distribution position detection microswitch (1 of 1)
2 3 CLUTCH (+)
6 7 SIG (+)
AC HOUSING,
BLOWER MOTOR
BLOWER REGULATOR
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CAN B H
CAN B L
CENTRAL AIR DISTRIBUTION POSITION DETECTION MICROSWITCH
CLIMATE CONTROL UNIT (RIGHT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DRIVER-SIDE FUSE, RELAY MODULE
EVAPORATOR TEMPERATURE SENSOR
FUSE 210
FUSE 3
FUSE 5
FUSE 6
GRN WIRE
GRN/VIO WIRE
GRY/RED WIRE
HOT AT ALL TIMES
LEFT FOOTWELL AIR OUTLET TEMPERATURE SENSOR
MULTIPLE FUSE 2
MULTIPLE FUSE 3
NCA WIRE
PASSENGER-SIDE A-PILLAR FUSE BOX
PNK WIRE
PTC HEATER BOOSTER (IF EQUIPPED)
REAR CENTER AIR VENT AIR OUTLET TEMPERATURE SENSOR
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FOOTWELL AIR OUTLET TEMPERATURE SENSOR
SIG
SIG GND
STATIONARY HEATER UNIT
VALVE
VEHICLE INTERIOR PREFUSE BOX
WHT WIRE
WHT/BLU WIRE
WINDSHIELD HEATER CONTROL UNIT
YEL WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit (1 of 3) -> CENTRAL AIR DISTRIBUTION POSITION DETECTION MICROSWITCH
