Tire pressure monitoring circuit for Mercedes-Benz CLS-class AMG C218/X218 (2010-2014)

BRN WIRE CAN E H CAN E L COMPUTER DATA LINES SYSTEM FRONT SAM CONTROL MODULE W/ FUSE/ RELAY MODULE FUSE 5 FUSE 70 GRN WIRE GRN/WHT WIRE HOT W/ CIRCUIT 15 RELAY ENERGIZED HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED INSTRUMENT CLUSTER LEFT FRONT TPM (RDK) TIRE PRESSURE SENSOR LEFT REAR TPM (RDK) TIRE PRESSURE SENSOR PNK WIRE REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE RED WIRE RED/PNK WIRE RED/WHT WIRE RIGHT FRONT TPM (RDK) TIRE PRESSURE SENSOR RIGHT REAR TPM (RDK) TIRE PRESSURE SENSOR TIRE PRESSURE MONITOR WARNING IND LAMP TPM CONTROL MODULE WHT WIRE
