Emergency seat belt tensioners circuit for Mercedes-Benz CLS-class AMG C218/X218 (2010-2014)
Emergency seat belt tensioners circuit
BLU WIRE
BRN WIRE
CAN E H
CAN E L
COMPUTER DATA LINES SYSTEM
FUSE 50
FUSE 51
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR ACTUATOR MOTOR
REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR ACTUATOR MOTOR
