High/low bus circuit for Mercedes-Benz CLS-class AMG C218/X218 (2010-2014)

AUDIO/COMMAND CONTROL PANEL AUDIO/COMMAND DISPLAY BLK WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRN WIRE CAN A H CAN A L CAN C H CAN C L CAN-G H CAN-G L CRADLE FOR NAVIGATION MODULE DIRECT SELECT INTELLIGENT SERVO MODULE DRIVE TRAIN CAN VOLTAGE DISTRIBUTOR ELECTRICAL CONNECTOR FUEL PUMP CONTROL UNIT FULLY INTEGRATED TRANSMISSION CONTROL UNIT LEFT FRONT LAMP UNIT LEFT HEADLAMP CONTROL UNIT ME-SFI (ME) CONTROL UNIT NAVIGATION MODULE RIGHT FRONT LAMP UNIT RIGHT HEADLAMP CONTROL UNIT TELEMATICS CAN VOLTAGE DISTRIBUTOR ELECTRICAL CONNECTOR TRANSMISSION OIL AUXILIARY PUMP CONTROL UNIT TV TUNER (IF EQUIPPED) TV DIGITAL TUNER (IF EQUIPPED) (RIGHT SIDE OF TRUNK) W/ DIRECT SELECT W/ DIRECT SELECT INTELLIGENT SERVO MODULE W/O DIRECT SELECT YEL WIRE YEL/WHT WIRE

ACTIVE MULTICONTOUR SEAT PNEUMATIC PUMP ANALOG CLOCK AUTOMATIC TRANSMISSION MODE BUTTON BACKUP CAMERA BACKUP CAMERA CONTROL UNIT BLK WIRE BLK/WHT WIRE BRN WIRE BRN/RED WIRE CAN A H CAN A L CAN B H CAN B L CAN E H CAN E L CAN-D H CAN-D L CAN-G H CAN-G L COMMAND CONTROL UNIT DIAGNOSTIC CONNECTOR DRIVER SEAT CONTROL UNIT ELECTRICAL POWER STEERING CONTROL UNIT FRONT END CAN (CAN G) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR FRONT SAM CONTROL UNIT W/ FUSE, RELAY MODULE GRN WIRE GRN/WHT WIRE GRY WIRE GRY/WHT WIRE LEFT FRONT ACTIVE MULTICONTOUR SEAT CONTROL UNIT LEFT FRONT DOOR CONTROL UNIT LEFT REAR BUMPER INTELLIGENT RADAR SENSOR LEFT REAR DOOR CONTROL UNIT LEFT VEHICLE FLOOR INTERIOR CAN VOLTAGE DISTRIBUTOR ELECTRICAL CONNECTOR LIN 1 NCA WIRE ORG/ WIRE OVERHEAD CONTROL PANEL CONTROL UNIT RADIO (AUDIO 20) RADIO W/ AUTO PILOT SYSTEM RIGHT REAR BUMPER INTELLIGENT RADAR SENSOR SUSPENSION BUTTON GROUP TRUNK LID CONTROL UNIT UPPER CONTROL PANEL CONTROL UNIT VIO WIRE VIO/WHT WIRE W/ AUDIO 20, AUDIO 50 W/ SPEED-SENSITIVE POWER STEERING W/ AIRMATIC W/O AUDIO 20, AUDIO 50 YEL WIRE YEL/WHT WIRE

ALTERNATOR BATTERY SENSOR BLU/WHT WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE CAN B H CAN B L CAN E H CAN E L FRONT PASSENGER SEAT CONTROL UNIT GRN WIRE GRN/WHT WIRE KEYLESS-GO CONTROL UNIT LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR LIN ME-SFI (ME) CONTROL UNIT ORG/ WIRE REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE REAR SEAT HEATERS CONTROL UNIT RIGHT FRONT ACTIVE MULTICONTOUR SEAT CONTROL UNIT RIGHT FRONT DOOR CONTROL UNIT RIGHT REAR DOOR RIGHT REAR DOOR CONTROL UNIT RIGHT VEHICLE FLOOR INTERIOR CAN VOLTAGE DISTRIBUTOR ELECTRICAL CONNECTOR STATIONARY HEATER UNIT TIRE PRESSURE MONITOR CONTROL UNIT TRAILER RECOGNITION CONTROL UNIT VEHICLE FLOOR CHASSIS CAN VOLTAGE DISTRIBUTOR ELECTRICAL CONNECTOR WEIGHT SENSING SYSTEM (WSS) CONTROL UNIT

AIRMATIC CONTROL UNIT AUTOMATIC AIR CONDITIONING CONTROL, OPERATING UNIT BRN WIRE BRN/RED WIRE CAN B H CAN B L CAN E H CAN E L CAN H H CAN H L DISTRONIC ELECTRIC CONTROLLER UNIT ELECTRONIC IGNITION SWITCH CONTROL UNIT ELECTRONIC STABILITY PROGRAM CONTROL UNIT GRN WIRE GRN/WHT WIRE INSTRUMENT CLUSTER MULTI-FUNCTION CAMERA NIGHT VISION ASSIST CONTROL UNIT PARKING SYSTEM CONTROL UNIT PREMIUM ELECTRONIC STABILITY PROGRAM CONTROL UNIT RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR STEERING COLUMN MODULE CONTROL UNIT STEERING WHEEL HEATER CONTROL UNIT SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT VEHICLE DYNAMICS CAN VOLTAGE DISTRIBUTOR ELECTRICAL CONNECTOR VIDEO, RADAR SENSOR SYSTEM CONTROL UNIT VIO WIRE VIO/WHT WIRE W/ ESP BASIC W/ ESP PREMIUM YAW RATE, LATERAL, LONGITUDINAL ACCELERATION SENSOR
