Mercedes-Benz CLS-class AMG C218/X218 (2010-2014) upstream throttle valve pressure sensor Wiring diagram

BLK/BRN WIRE BLK/ORG WIRE BLK/YEL WIRE BLU/BRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/WHT WIRE CAMSHAFT HALL SENSOR CHARGE AIR TEMPERATURE SENSOR CYLINDER IGNITION COILS 1, 2, 3, 4 GRN WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/ORG WIRE GRN/PNK WIRE GRN/RED WIRE GRY/BRN WIRE GRY/PNK WIRE GRY/RED WIRE GRY/YEL WIRE LEFT AIR FILTER PRESSURE SENSOR DOWNSTREAM LEFT EXHAUST CAMSHAFT HALL SENSOR LEFT INTAKE CAMSHAFT HALL SENSOR LEFT OXYGEN DOWNSTREAM CATALYTIC CONVERTER SENSOR NCA WIRE OIL LEVEL CHECK SWITCH PNK WIRE PNK/GRN WIRE PNK/YEL WIRE RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RIGHT CYLINDER BANK DOWNSTREAM AIR FILTER PRESSURE SENSOR RIGHT OXYGEN DOWNSTREAM CATALYTIC CONVERTER SENSOR SPARK PLUGS THROTTLE VALVE DOWNSTREAM PRESSURE SENSOR UPSTREAM THROTTLE VALVE PRESSURE SENSOR VIO WIRE VIO/WHT WIRE WHT/BLK WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/WHT WIRE
