Mercedes-Benz CLS-class AMG C218/X218 (2010-2014) trunk lid control drive unit Wiring diagrams
This page contains all the electrical diagrams for the component. trunk lid control drive unit, in which he is found in the car Mercedes-Benz CLS-class AMG C218/X218 (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram trunk lid control drive unit (1 of 2)
15 RELAY (DIAGRAM 2 OF 5) TO FUSE 89 (DIAGRAM 2 OF 5)
AC HOUSING,
ADDITIONAL BATTERY CIRCUIT 30 FUSE
AIRMATIC RELAY
ALARM SIREN
ALTERNATOR
BATTERY SENSOR
BLK WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
COMBUSTION ENGINE, AIR CONDITIONING W/ INTEGRATED CONTROL FAN MOTOR
CONTROL UNIT)
COOLANT CIRCULATION PUMP RELAY
ECO START/STOP FUNCTION ADDITIONAL BATTERY
ECO START/STOP FUNCTION ADDITIONAL BATTERY RELAY
ELECTRICAL POWER STEERING CONTROL UNIT
FROM FUSE 157 (DIAGRAM 1 OF 5)
FUSE
FUSE 150
FUSE 151
FUSE 152
FUSE 154
FUSE 155
FUSE 156
FUSE 157 155
FUSE 158
FUSE 160
FUSE 162 161
FUSE 163
FUSE 164
FUSE 39
FUSE 41
FUSE 46
FUSE 61
FUSE 66
FUSE 88
GRY/YEL WIRE
INTELLIGENT SERVO MODULE FOR DIRECT SELECT
INTERFERENCE SUPPRESSION CAPACITOR
INTERIOR PROTECTION, TOW-AWAY PROTECTION CONTROL UNIT
ISM
LEFT REAR DOOR CONTROL UNIT
NCA WIRE
ON-BOARD ELECTRICAL SYSTEM BATTERY
PTC HEATER BOOSTER
QUIESCENT CURRENT CUTOUT RELAY
REAR BLOWER MOTOR
REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE CIRCUIT 30 FUSE
REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE
REAR WINDOW ANTENNA AMPLIFIER 1
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR CONTROL UNIT
STARTER
SUPPLEMENTAL RESTRAINT SYSTEM
TERMINAL BLOCK (CIRCUIT 30)
TO CIRCUIT
TO FRONT SAM CONTROL MODULE W/ FUSE, RELAY MODULE (DIAGRAM 4 OF 5)
TO FRONT SAM CONTROL MODULE W/ FUSE, RELAY MODULE (DIAGRAM 5 OF 5)
TO FUSE 155 (DIAGRAM 1 OF 5)
TRUNK LID CONTROL DRIVE UNIT
VIO/BLU WIRE
W/ ECO START/ STOP SYSTEM W/O ECO START/ STOP SYSTEM
WHT/GRN WIRE
Go to component -> Power distribution circuit (1 of 5) -> TRUNK LID CONTROL DRIVE UNIT
Wiring diagram trunk lid control drive unit (2 of 2)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
FRONT SAM CONTROL UNIT W/ FUSE, RELAY MODULE
FUSE 2
FUSE 61
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/PNK WIRE
HOT AT ALL TIMES
HOT W/
LEFT FRONT DOOR CONTROL MODULE
ORG/ WIRE
ORG/GRN WIRE
QUIESCENT CURRENT CUTOUT RELAY ENERGIZED
REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
SIG
TRUNK LID CONTROL DRIVE UNIT
TRUNK LID EMERGENCY OPENING BUTTON
TRUNK LID RELEASE BUTTON
TRUNK LID/ LIFTGATE CONTROL DRIVE UNIT
TRUNK LID/ LIFTGATE POSITION SENSOR
TRUNK LID/LIFTGATE CENTRAL LOCKING MOTOR
TRUNK LID/LIFTGATE CONTACT SWITCH
TRUNK LID/LIFTGATE CONTROL BUTTON
TRUNK LID/LIFTGATE EXTERNAL OPERATION SWITCH
TRUNK LID/LIFTGATE LOCKING ELEMENT
TRUNK LID/LIFTGATE LOCKING ELEMENT (RIGHT REAR OF TRUNK)
VIO WIRE
VIO/GRN WIRE
WHT WIRE
YEL WIRE
YEL/GRN WIRE
ZV-MOT +
Go to component -> Trunk pull-down circuit -> TRUNK LID CONTROL DRIVE UNIT
