Mercedes-Benz CLS-class AMG C218/X218 (2010-2014) sdar control unit/ high definition tuner Wiring diagram
This page shows the only wiring diagram for the component.sdar control unit/ high definition tuner, which is found in the car Mercedes-Benz CLS-class AMG C218/X218 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sdar control unit/ high definition tuner (1 of 1)
AAG
ACTIVE MULTICONTOUR SEAT PNEUMATIC PUMP
AIRMATIC CONTROL UNIT
BACKUP CAMERA VOLTAGE SUPPLY MODULE
BLK/GRN WIRE
BRN WIRE
CIRCUIT 15 RELAY
CONTROL UNIT (IF EQUIPPED)
DIGITAL AUDIO BROADCASTING CONTROL UNIT
DRIVER SEAT CONTROL UNIT
DRIVER SEAT NECK-PRO HEAD RESTRAINT SOLENOID
EMERGENCY CALL SYSTEM
FROM FUSE 41 (DIAGRAM 1 OF 5)
FRONT CIGARETTE LIGHTER W/ ASHTRAY ILLUMINATION
FRONT PASSENGER SEAT CONTROL UNIT
FRONT PASSENGER SEAT NECK-PRO HEAD RESTRAINT SOLENOID
FRONT VEHICLE INTERIOR POWER OUTLET
FUEL PUMP CONTROL UNIT
FUEL PUMP RELAY
FUSE 37
FUSE 38
FUSE 42
FUSE 48
FUSE 55
FUSE 56
FUSE 59
FUSE 60
FUSE 62
FUSE 63
FUSE 64
FUSE 68
FUSE 71
FUSE 83
FUSE 84
FUSE 86
FUSE 87
FUSE 89
FUSE 90
GRY WIRE
GRY/BLU WIRE
MULTICONTOUR SEAT PNEUMATIC PUMP
N/A
NAVIGATION PROCESSOR
NCA WIRE
ORG/RED WIRE
PNK/GRN WIRE
REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE
REAR SEAT HEATERS CONTROL UNIT
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
SCR
SDAR CONTROL UNIT/ HIGH DEFINITION TUNER
SEAT ADJUSTMENT RELAY
TAILGATE WINDSHIELD WIPER RELAY
TO FUSE 42 (DIAGRAM 2 OF 5)
TRAILER RECOGNITION CONTROL UNIT
TRAILER SOCKET
VIO/RED WIRE
W/ INTELLIGENT SERVO MODULE FOR DIRECT SELECT
W/O SMOKER PACKAGE
YEL/RED WIRE
Go to component -> Power distribution circuit (2 of 5) -> SDAR CONTROL UNIT/ HIGH DEFINITION TUNER
