Mercedes-Benz CLS-class AMG C218/X218 (2010-2014) right front seat massage function actuator motor Wiring diagram

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/PNK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/GRY WIRE BRN/RED WIRE BRN/YEL WIRE CAN B H CAN B L COMPUTER DATA LINES SYSTEM DYNAMIC BUTTON END FRONT PASSENGER ACTIVE MULTICONTOUR SEAT BUTTON GROUP FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT CONTROL UNIT FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH FRONT PASSENGER SEAT LUMBAR SUPPORT PNEUMATIC PUMP FUSE 41 GRN WIRE GRN/BLU WIRE GRN/GRY WIRE GRN/ORG WIRE GRN/PNK WIRE GRY WIRE HOT AT ALL TIMES LUMBAR SUPPORT +/- ADJUSTMENT BUTTON LUMBAR SUPPORT UP/ DOWN ADJUSTMENT BUTTON MESSAGE FUNCTION BUTTON REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT ACTIVE MULTICONTOUR SEAT CONTROL UNIT RIGHT FRONT DOOR CONTROL UNIT RIGHT FRONT SEAT ADJUSTMENT SWITCH GROUP RIGHT FRONT SEAT MASSAGE FUNCTION ACTUATOR MOTOR SEAT CUSHION LENGTH BUTTON SEAT SIDE BOLSTER AIR CUSHION ADJUSTMENT BUTTON SIG W/ ACTIVE MULTICONTOUR SEAT W/0 ACTIVE MULTICONTOUR SEAT WHT WIRE YEL WIRE
