Mercedes-Benz CLS-class AMG C218/X218 (2010-2014) ram air flap actuator motor Wiring diagram
This page shows the only wiring diagram for the component.ram air flap actuator motor, which is found in the car Mercedes-Benz CLS-class AMG C218/X218 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ram air flap actuator motor (1 of 1)
AC HOUSING,
BLK WIRE
BLK/RED WIRE
BLOWER MOTOR
BLOWER REGULATOR
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
FRESH AIR/AIR RECIRCULATION FLAP ACTUATOR MOTOR
FUSE 46
FUSE 66
GRN/BRN WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
INTERIOR TEMPERATURE SENSOR W/ INTEGRATED FAN
LEFT CENTER AIR OUTLET SYMBOL ILLUMINATION
LEFT FRONT SIDE AIR OUTLET SYMBOL ILLUMINATION
LIN
OVERHEAD CONTROL PANEL CONTROL MODULE
OVERHEAD CONTROL PANEL ELECTRONICS
RAM AIR FLAP ACTUATOR MOTOR
REAR AIR OUTLET SYMBOL ILLUMINATION
REAR AUTOMATIC AIR CONDITIONING OPERATING UNIT
REAR BLOWER MOTOR
REAR FOOTWELL AIR OUTLET TEMPERATURE SENSOR
REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT BLENDING AIR FLAP ACTUATOR
RIGHT CENTER AIR OUTLET SYMBOL ILLUMINATION
RIGHT FRONT SIDE AIR OUTLET SYMBOL ILLUMINATION
VEHICLE INTERIOR HUMIDITY/ TEMPERATURE SENSOR
VIO/BLU WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/RED WIRE
VIO/WHT WIRE
VIO/YEL WIRE
W/ AIR OUTLET SYMBOL ILLUMINATION
W/ DIRECT SELECT
W/O DIRECT SELECT
WHT WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, w/ 3-zone (2 of 3) -> RAM AIR FLAP ACTUATOR MOTOR
