Mercedes-Benz CLS-class AMG C218/X218 (2010-2014) navigation module Wiring diagrams
This page contains all the electrical diagrams for the component. navigation module, in which he is found in the car Mercedes-Benz CLS-class AMG C218/X218 (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram navigation module (1 of 3)
AUDIO/COMMAND CONTROL PANEL
AUDIO/COMMAND DISPLAY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CAN A H
CAN A L
CAN C H
CAN C L
CAN-G H
CAN-G L
CRADLE FOR NAVIGATION MODULE
DIRECT SELECT INTELLIGENT SERVO MODULE
DRIVE TRAIN CAN VOLTAGE DISTRIBUTOR ELECTRICAL CONNECTOR
FUEL PUMP CONTROL UNIT
FULLY INTEGRATED TRANSMISSION CONTROL UNIT
LEFT FRONT LAMP UNIT
LEFT HEADLAMP CONTROL UNIT
ME-SFI (ME) CONTROL UNIT
NAVIGATION MODULE
RIGHT FRONT LAMP UNIT
RIGHT HEADLAMP CONTROL UNIT
TELEMATICS CAN VOLTAGE DISTRIBUTOR ELECTRICAL CONNECTOR
TRANSMISSION OIL AUXILIARY PUMP CONTROL UNIT
TV TUNER (IF EQUIPPED) TV DIGITAL TUNER (IF EQUIPPED) (RIGHT SIDE OF TRUNK)
W/ DIRECT SELECT
W/ DIRECT SELECT INTELLIGENT SERVO MODULE
W/O DIRECT SELECT
YEL WIRE
YEL/WHT WIRE
Go to component -> High/low bus circuit (1 of 4) -> NAVIGATION MODULE
Wiring diagram navigation module (2 of 3)
ANT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CAN A H
CAN A L
COMPUTER DATA LINES SYSTEM
CRADLE FOR NAVIGATION MODULE
FM/TMC ANTENNA SPLITTER
FRONT SAM CONTROL UNIT W/ FUSE, RELAY MODULE
FUSE 11
GPS
GRN WIRE
HOT AT ALL TIMES
LVDS
MIC -
MULTI-FUNCTION ANTENNA
NAVIGATION MODULE
NCA WIRE
ORG/ WIRE
RADIO
RED/GRN WIRE
RES+
SHIELD
TMC
VOICE
WHT WIRE
Go to component -> Navigation circuit -> NAVIGATION MODULE
Wiring diagram navigation module (3 of 3)
30 FUSE (DIAGRAM 1 OF 5)
ANALOG CLOCK
AUDIO/ COMAND DISPLAY
AUDIO/COMAND CONTROL PANEL
AUTOMATIC AIR CONDITIONING CONTROL, OPERATING UNIT
AUTOMATIC TRANSMISSION MODE BUTTON
BACKUP RELAY
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BRN WIRE
CENTER CONSOLE SOCKET
CIRCUIT 15 RELAY
CONTROL UNIT)
ENGINE CIRCUIT 87 RELAY
EXTERIOR LIGHT SWITCH
FANFARE HORN RELAY
FROM ADDITIONAL BATTERY CIRCUIT
FROM ECO START/STOP FUNCTION ADDITIONAL BATTERY RELAY (DIAGRAM 1 OF 5)
FROM FRONT ELECTRICAL PREFUSE BOX (DIAGRAM 1 OF 5)
FROM FRONT SAM CONTROL MODULE W/ FUSE, RELAY MODULE (DIAGRAM 4 OF 5)
FRONT SAM CONTROL UNIT W/ FUSE, RELAY MODULE
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 15
FUSE 16
FUSE 17
FUSE 18
FUSE 21
FUSE 29
FUSE 30
FUSE 32
FUSE 4
FUSE 5
FUSE 6
FUSE 8
FUSE 9
GLOVE BOX LAMP/ SWITCH
GRY/YEL WIRE
INSTRUMENT CLUSTER
LEFT FRONT LAMP UNIT
ME-SFI (ME) CONTROL UNIT
MULTI-FUNCTION CAMERA
NAVIGATION MODULE
OVERHEAD CONTROL PANEL CONTROL UNIT
PNK/BLU WIRE
PNK/RED WIRE
REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/PNK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT LAMP UNIT
SECONDARY AIR INJECTION RELAY
STEERING COLUMN MODULE CONTROL UNIT
STOP LAMP SWITCH
SUPPLEMENTAL RESTARAINT SYSTEM
SUPPLEMENTAL RESTRAINT SYSTEM
TRANSMISSION OIL AUXILIARY PUMP CONTROL UNIT
UPPER CONTROL PANEL CONTROL UNIT
WEIGHT SENSING SYSTEM
WIPER MOTOR
WIPER PARK HEATER
WIPER PARK POSITION HEATER RELAY
YEL/BLK WIRE
Go to component -> Power distribution circuit (4 of 5) -> NAVIGATION MODULE
