Mercedes-Benz CLS-class AMG C218/X218 (2010-2014) left rear bank cylinder knock sensor Wiring diagram

BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/YEL WIRE CAM B H CAM B L CAN C H CAN C L COMBUSTION ENGINE/AIR CONDITIONING INTEGRATED CONTROL FAN MOTOR COMPUTER DATA LINES SYSTEM EKP FUEL PRESSURE SENSOR FUEL PUMP FUEL PUMP CONTROL UNIT FUSE 42 GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/WHT WIRE GRY/BLK WIRE GRY/BLU WIRE HOT AT ALL TIMES LEFT FRONT BANK CYLINDER KNOCK SENSOR LEFT FUEL TANK FUEL LEVEL INDICATOR FILL LEVEL SENSOR LEFT REAR BANK CYLINDER KNOCK SENSOR NCA WIRE PNK/BLK WIRE PNK/BLU WIRE REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RIGHT FRONT BANK CYLINDER KNOCK SENSOR RIGHT FUEL TANK FUEL LEVEL INDICATOR FILL LEVEL SENSOR RIGHT REAR BANK CYLINDER KNOCK SENSOR SIG VIO WIRE VIO/BLK WIRE VIO/BLU WIRE WHT WIRE
