Mercedes-Benz CLS-class AMG C218/X218 (2010-2014) left front active multicontour seat control unit Wiring diagrams
This page contains all the electrical diagrams for the component. left front active multicontour seat control unit, in which he is found in the car Mercedes-Benz CLS-class AMG C218/X218 (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front active multicontour seat control unit (1 of 2)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/PNK WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/YEL WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
DRIVER ACTIVE MULTICONTOUR SEAT BUTTON GROUP
DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT CONTROL UNIT
DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
DRIVER SEAT LUMBAR SUPPORT PNEUMATIC PUMP
DYNAMIC BUTTON
END
FRONT SAM CONTROL MODULE W/ FUSE, RELAY UNIT
FUSE 2
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/ORG WIRE
GRN/PNK WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT ACTIVE MULTICONTOUR SEAT CONTROL UNIT
LEFT FRONT DOOR CONTROL UNIT
LEFT FRONT SEAT ADJUSTMENT SWITCH GROUP
LEFT FRONT SEAT MASSAGE FUNCTION ACTUATOR MOTOR
LUMBAR SUPPORT +/- ADJUSTMENT BUTTON
LUMBAR SUPPORT UP/ DOWN ADJUSTMENT BUTTON
MESSAGE FUNCTION BUTTON
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
SEAT CUSHION LENGTH BUTTON
SEAT SIDE BOLSTER AIR CUSHION ADJUSTMENT BUTTON
SIG
W/ ACTIVE MULTICONTOUR SEAT W/0 ACTIVE MULTICONTOUR SEAT
WHT WIRE
YEL WIRE
Go to component -> Driver"s memory seat circuit (2 of 2) -> LEFT FRONT ACTIVE MULTICONTOUR SEAT CONTROL UNIT
Wiring diagram left front active multicontour seat control unit (2 of 2)
ACTIVE MULTICONTOUR SEAT PNEUMATIC PUMP
ANALOG CLOCK
AUTOMATIC TRANSMISSION MODE BUTTON
BACKUP CAMERA
BACKUP CAMERA CONTROL UNIT
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/RED WIRE
CAN A H
CAN A L
CAN B H
CAN B L
CAN E H
CAN E L
CAN-D H
CAN-D L
CAN-G H
CAN-G L
COMMAND CONTROL UNIT
DIAGNOSTIC CONNECTOR
DRIVER SEAT CONTROL UNIT
ELECTRICAL POWER STEERING CONTROL UNIT
FRONT END CAN (CAN G) POTENTIAL DISTRIBUTOR ELECTRICAL CONNECTOR
FRONT SAM CONTROL UNIT W/ FUSE, RELAY MODULE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/WHT WIRE
LEFT FRONT ACTIVE MULTICONTOUR SEAT CONTROL UNIT
LEFT FRONT DOOR CONTROL UNIT
LEFT REAR BUMPER INTELLIGENT RADAR SENSOR
LEFT REAR DOOR CONTROL UNIT
LEFT VEHICLE FLOOR INTERIOR CAN VOLTAGE DISTRIBUTOR ELECTRICAL CONNECTOR
LIN 1
NCA WIRE
ORG/ WIRE
OVERHEAD CONTROL PANEL CONTROL UNIT
RADIO (AUDIO 20)
RADIO W/ AUTO PILOT SYSTEM
RIGHT REAR BUMPER INTELLIGENT RADAR SENSOR
SUSPENSION BUTTON GROUP
TRUNK LID CONTROL UNIT
UPPER CONTROL PANEL CONTROL UNIT
VIO WIRE
VIO/WHT WIRE
W/ AUDIO 20, AUDIO 50
W/ SPEED-SENSITIVE POWER STEERING W/ AIRMATIC
W/O AUDIO 20, AUDIO 50
YEL WIRE
YEL/WHT WIRE
Go to component -> High/low bus circuit (2 of 4) -> LEFT FRONT ACTIVE MULTICONTOUR SEAT CONTROL UNIT
