Mercedes-Benz CLS-class AMG C218/X218 (2010-2014) hands-free system microphone Wiring diagrams
This page contains all the electrical diagrams for the component. hands-free system microphone, in which he is found in the car Mercedes-Benz CLS-class AMG C218/X218 (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram hands-free system microphone (1 of 4)
ANST
AUDIO/COMMAND DISPLAY
AUX JACK ELECTRICAL CONNECTOR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
BRN/GRN WIRE
BRN/ORG WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN A H
CAN A L
CAN B H
CAN B L
CELLULAR TELEPHONE SYSTEM ANTENNA AMPLIFIER/COMPENSATOR
COMMAND CONTROL UNIT
COMMAND FAN MOTOR
COMPUTER DATA LINES SYSTEM
DIAG
EMERGENCY CALL SYSTEM CONTROL UNIT
FRONT SAM CONTROL MODULE W/ FUSE/ RELAY MODULE
FUSE 11
FUSE 26
GND CD 1
GRN WIRE
GRY WIRE
GRY/YEL WIRE
HANDS-FREE SYSTEM MICROPHONE
HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED
INSIDE REARVIEW MIRROR
KEEP ON
LEFT FRONT DOOR BASS SPEAKER
LEFT FRONT DOOR TWEETER
LEFT REAR DOOR BASS SPEAKER
LEFT REAR DOOR TWEETER
LR (-)
LVDS
MIC -
MIC 2+
MOBILE PHONE ELECTRICAL CONNECTOR
MOST DATA BUS CIRCUIT
MOST IN
MOST OUT
NCA WIRE
ORG/ WIRE
PNK MIC 1+ WIRE
PNK WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RES+
RIGHT REAR DOOR BASS SPEAKER
RIGHT REAR DOOR TWEETER
SHIELD
USB
USB BUS
USB CONNECTOR
USB USB
VIO WIRE
W/ COMMAND
W/O COMMAND
W/O SOUND SYSTEM
WAKE-UP
WHT WIRE
YEL WIRE
Go to component -> Comand actuation circuit (1 of 3) -> HANDS-FREE SYSTEM MICROPHONE
Wiring diagram hands-free system microphone (2 of 4)
AMBIENT LAMP
ASS LED
ASS OFF
AUTOMATIC DIMMING MIRROR
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/YEL WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
FL (-)
FORWARD AUTOMATIC DIMMING MIRROR LIGHT SENSOR
FRONT DOME LAMP SWITCH
FRONT SAM CONTROL UNIT W/ FUSE, RELAY MODULE
FUSE 46
GARAGE DOOR OPENER
GARAGE DOOR OPENER BUTTON 1
GARAGE DOOR OPENER BUTTON 2
GARAGE DOOR OPENER BUTTON 3
GARAGE DOOR OPENER INDICATOR LAMP
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HANDS-FREE SYSTEM MICROPHONE
HOT AT ALL TIMES
INFO
INFO LED
INSIDE REARVIEW MIRROR
INTERIOR LAMP AUTOMATIC FUNCTION SWITCH
INTERIOR PROTECTION RECEIVER
INTERIOR PROTECTION SWITCH
INTERIOR PROTECTION, TOW-AWAY PROTECTION CONTROL UNIT
INTERIOR TEMPERATURE SENSOR W/ INTEGRATED FAN
IRS LED
IRS-OFF
LEFT FRONT INTERIOR LAMP
LEFT FRONT READING LAMP SWITCH
LEFT INTERIOR PROTECTION TRANSMITTER
LEFT READING LAMP
LIN 2
LL L
LL R
NAVIGATION SYSTEM
NCA WIRE
NTC-
ORG/ WIRE
OVERHEAD CONTROL PANEL CONTROL ELECTRONICS
PNK WIRE
RAIN/LIGHT SENSOR
REAR DOME LAMP, SWITCH
REAR SAM CONTROL UNIT W/ FUSE, RELAY MODULE
REARWARD AUTOMATIC DIMMING MIRROR LIGHT SENSOR
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT INTERIOR LAMP
RIGHT FRONT READING LAMP SWITCH
RIGHT INTERIOR PROTECTION TRANSMITTER
RIGHT READING LAMP
SIG IL
SOS
SOS LED
TOWING SENSOR BUTTON
VIO WIRE
VIO/BLU WIRE
WHT WIRE
WS LED
YEL WIRE
YEL/VIO WIRE
Go to component -> Overhead console circuit, w/o sunroof -> HANDS-FREE SYSTEM MICROPHONE
Wiring diagram hands-free system microphone (3 of 4)
AMBIENT LAMP
ASS LED
ASS OFF
AUTOMATIC DIMMING MIRROR
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/YEL WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
EMERGENCY CALL SYSTEM CONTROL UNIT
FL (-)
FORWARD AUTOMATIC DIMMING MIRROR LIGHT SENSOR
FRONT DOME LAMP SWITCH
FRONT SAM CONTROL UNIT W/ FUSE, RELAY MODULE
FUSE 17
GARAGE DOOR OPENER
GARAGE DOOR OPENER BUTTON 1
GARAGE DOOR OPENER BUTTON 2
GARAGE DOOR OPENER BUTTON 3
GARAGE DOOR OPENER INDICATOR LAMP
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/YEL WIRE
HANDS-FREE SYSTEM MICROPHONE
HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED
HS(+) HS 2
INFO
INFO LED
INSIDE REARVIEW MIRROR
INTERIOR LAMP AUTOMATIC FUNCTION SWITCH
INTERIOR PROTECTION RECEIVER
INTERIOR PROTECTION SWITCH
INTERIOR PROTECTION, TOW-AWAY PROTECTION CONTROL UNIT
INTERIOR TEMPERATURE SENSOR W/ INTEGRATED FAN
IRS LED
IRS-OFF
LEFT FRONT INTERIOR LAMP
LEFT FRONT READING LAMP SWITCH
LEFT INTERIOR PROTECTION TRANSMITTER
LEFT READING LAMP
LIN
LIN 2
LL L
LL R
MOTOR
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
OVERHEAD CONTROL PANEL CONTROL UNIT
PNK WIRE
POWER TOPS SYSTEM
RAIN/LIGHT SENSOR
REAR DOME LAMP, SWITCH
REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE
REARWARD AUTOMATIC DIMMING MIRROR LIGHT SENSOR
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT INTERIOR LAMP
RIGHT FRONT READING LAMP SWITCH
RIGHT INTERIOR PROTECTION TRANSMITTER
RIGHT READING LAMP
SOS
SOS LED
TILTING/SLIDING ROOF SWITCH
TOWING SENSOR BUTTON
VIO WIRE
WHT WIRE
WS LED
YEL WIRE
YEL/VIO WIRE
Go to component -> Overhead console circuit, w/ sunroof -> HANDS-FREE SYSTEM MICROPHONE
Wiring diagram hands-free system microphone (4 of 4)
AMBIENT LAMP
AUTOMATIC DIMMING MIRROR
BLK WIRE
BLU WIRE
BRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
CAN B H
CAN B L
COMPUTER DATA LINES SYSTEM
FORWARD AUTOMATIC DIMMING MIRROR LIGHT SENSOR
FRONT SAM CONTROL MODULE W/ FUSE/ RELAY MODULE
FUSE 17
FUSE 2
GARAGE DOOR OPENER
GARAGE DOOR OPENER BUTTON 1
GARAGE DOOR OPENER BUTTON 2
GARAGE DOOR OPENER BUTTON 3
GARAGE DOOR OPENER INDICATOR LAMP
GRN WIRE
GRY WIRE
GRY/YEL WIRE
HANDS-FREE SYSTEM MICROPHONE
HOT AT ALL TIMES
HOT W/ QUIESCENT CURRENT CUT-OUT RELAY ENERGIZED
INSIDE REARVIEW MIRROR
LEFT FRONT DOOR CONTROL UNIT
LEFT OUTSIDE MIRROR
LEFT READING LAMP
LIN
LL L
LL R
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
OVERHEAD CONTROL PANEL CONTROL UNIT
OVERHEAD CONTROL PANEL ELECTRONICS
PNK WIRE
RAIN/LIGHT SENSOR
REARWARD AUTOMATIC DIMMING MIRROR LIGHT SENSOR
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT READING LAMP
SIG
USED)
VIO WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> HANDS-FREE SYSTEM MICROPHONE
