Mercedes-Benz CLS-class AMG C218/X218 (2010-2014) front sam control unit with fuse/ relay module Wiring diagram
This page shows the only wiring diagram for the component.front sam control unit with fuse/ relay module, which is found in the car Mercedes-Benz CLS-class AMG C218/X218 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front sam control unit with fuse/ relay module (1 of 1)
ANTILOCK BRAKE SYSTEM INDICATOR LAMP
BLK WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
BRN/BLK WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CAN B H
CAN B L
CAN E H
CAN E L
COMPUTER DATA LINES SYSTEM
ELECTRONIC STABILITY PROGRAM WARNING LAMP
FRONT SAM CONTROL UNIT WITH FUSE/ RELAY MODULE
FUSE 1
FUSE 14
FUSE 20
FUSE 21
FUSE 28
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT W/ CIRCUIT 15 RELAY ENERGIZED
INSTRUMENT CLUSTER
NCA WIRE
ORG/BLU WIRE
ORG/GRN WIRE
PARKING BRAKE INDICATOR SWITCH
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT BRAKE WEAR SENSOR
RIGHT REAR BRAKE WEAR SENSOR
SERVICE BRAKE INDICATOR LAMP
SPEED-SENSITIVE POWER STEERING SOLENOID VALVE
STEERING ANGLE SENSOR
STEERING COLUMN MODULE CONTROL UNIT
YAW RATE, LATERAL, LONGITUDINAL ACCELERATION SENSOR
Go to component -> Anti-lock brakes circuit, basic (2 of 2) -> FRONT SAM CONTROL UNIT WITH FUSE/ RELAY MODULE
