Mercedes-Benz CLS-class AMG C218/X218 (2010-2014) driver kneebag ignition squib Wiring diagram
This page shows the only wiring diagram for the component.driver kneebag ignition squib, which is found in the car Mercedes-Benz CLS-class AMG C218/X218 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver kneebag ignition squib (1 of 1)
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CAN E H
CAN E L
COMPUTER DATA LINES SYSTEM
DRIVER AIR BAG IGNITION SQUIB 1
DRIVER AIR BAG IGNITION SQUIB 2
DRIVER KNEEBAG IGNITION SQUIB
EMERGENCY CALL SYSTEM CONTROL UNIT
FANFARE HORNS, AIR BAG CLOCK SPRING CONTACT
FRONT PASSENGER AIR BAG IGNITION SQUIB 1
FRONT PASSENGER AIR BAG IGNITION SQUIB 2
FRONT PASSENGER KNEE AIR BAG SQUIB
FRONT PASSENGER SEAT OCCUPIED RECOGNITION, ACSR
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
INSTRUMENT CLUSTER
KB BF+
KB FA-
LEFT FRONT DOOR PRESSURE SENSOR
NCA WIRE
PNK/BLK WIRE
PNK/YEL WIRE
RED/BRN WIRE
RED/YEL WIRE
RIGHT FRONT DOOR PRESSURE SENSOR
STEERING COLUMN MODULE CONTROL UNIT
SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT
SUPPLEMENTAL RESTRAINT SYSTEM IND LAMP
VIO WIRE
VIO/GRN WIRE
VIO/YEL WIRE
WHT/BLK WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Supplemental restraint circuit (4 of 4) -> DRIVER KNEEBAG IGNITION SQUIB
