Mercedes-Benz CLS-class AMG C218/X218 (2010-2014) data link connector Wiring diagram
This page shows the only wiring diagram for the component.data link connector, which is found in the car Mercedes-Benz CLS-class AMG C218/X218 (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram data link connector (1 of 1)
ANTI-LOCK BRAKE SYSTEM INDICATOR LAMP
BLK WIRE
BLU/BRN WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE VACUUM SENSOR
BRN WIRE
BRN/BLK WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CAN E H
CAN E L
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR
ELECTRONIC STABILITY PROGRAM WARNING LAMP
FRONT SAM CONTROL MODULE W/ FUSE/ RELAY MODULE
FUSE 14
FUSE 21
FUSE 28
GRN WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT W/ CIRCUIT 15 RELAY ENERGIZED
INSTRUMENT CLUSTER
NCA WIRE
ORG/BLU WIRE
ORG/GRN WIRE
PARKING BRAKE INDICATOR SWITCH
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT FRONT BRAKE WEAR SENSOR
RIGHT REAR BRAKE WEAR SENSOR
SERVICE BRAKE INDICATOR LAMP
STEERING ANGLE SENSOR
STEERING COLUMN MODULE CONTROL UNIT
STOP LAMP SWITCH
VIO WIRE
VIO/WHT WIRE
W/ ECO START/ STOP FUNCTION
WHT WIRE
YAWRATE, LATERAL, LONGITUDINAL ACCELERATION SENSOR
YEL/RED WIRE
Go to component -> Anti-lock brakes circuit, premium (2 of 2) -> DATA LINK CONNECTOR
