Mercedes-Benz CLS-class AMG C218/X218 (2010-2014) coolant thermostat heating element Wiring diagram

BLK/BRN WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/WHT WIRE COOLANT THERMOSTAT HEATING ELEMENT CYLINDER IGNITION COILS 5, 6, 7, 8 FUEL TANK PRESSURE, TEMPERATURE SENSOR GRN WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/ORG WIRE GRN/PNK WIRE GRN/RED WIRE GRN/WHT WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/PNK WIRE GRY/RED WIRE GRY/WHT WIRE LEFT QUANTITY CONTROL VALVE PNK WIRE PNK/BRN WIRE PNK/GRN WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RIGHT EXHAUST CAMSHAFT HALL SENSOR RIGHT INTAKE CAMSHAFT HALL SENSOR RIGHT INTAKE CAMSHAFT SOLENOID RIGHT QUANTITY CONTROL VALVE SPARK PLUGS VIO WIRE VIO/BRN WIRE VIO/WHT WIRE WHT/BRN WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE
