Emergency seat belt tensioners circuit for Mercedes-Benz CLA-class C118 (2019-2023)
Emergency seat belt tensioners circuit
BRN WIRE
CAN HMI H
CAN HMI L
COMPUTER DATA LINES SYSTEM
FUSE 115
FUSE 119
HOT W/ BATTERY DISCONNECT SWITCH RELAY ENERGIZED
LEFT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
RED WIRE
RED/BLK WIRE
RIGHT FRONT REVERSIBLE EMERGENCY TENSIONING RETRACTOR
VEHICLE INTERIOR FUSE, RELAY MODULE
VIO WIRE
VIO/WHT WIRE
