Electronic suspension circuit for Mercedes-Benz CLA-class C117/X117 facelift (2016-2019)

ADAPTIVE DAMPING SYSTEM CONTROL UNIT BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/YEL WIRE BRN WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM FUSE 47 GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES LEFT FRONT AXLE DAMPING VALVE UNIT LEFT FRONT BODY LATERAL ACCELERATION SENSOR LEFT REAR AXLE DAMPING VALVE UNIT NCA WIRE REAR BODY ACCELERATION SENSOR RED/YEL WIRE RIGHT FRONT AXLE DAMPING VALVE UNIT RIGHT FRONT BODY LATERAL ACCELERATION SENSOR RIGHT REAR AXLE DAMPING VALVE UNIT SIG SIG (H) SIG (L) VEHICLE INTERIOR FUSE BOX VIO/BLU WIRE VIO/GRY WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE
