Mercedes-Benz CLA-class C117/X117 facelift (2016-2019) upper panel control unit Wiring diagram
This page shows the only wiring diagram for the component.upper panel control unit, which is found in the car Mercedes-Benz CLA-class C117/X117 facelift (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram upper panel control unit (1 of 1)
AUTOMATIC CHILD SEAT RECOGNITION AIR BAG OFF IND LAMP
BLK WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/PNK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
C SIG
CENTER REAR SEAT BELT BUCKLE SWITCH
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER SEAT OCCUPIED RECOGNITION, ACSR
FUSE 94
FUSE 95
GRY WIRE
GRY/BRN WIRE
GRY/YEL WIRE
HOT W/ CIRCUIT
LEFT REAR EMERGENCY TENSIONING RETRACTOR SQUIB
LEFT REAR SEAT BELT BUCKLE SWITCH
LEFT REAR SIDE BAG SQUIB
ME-SFI (ME) CONTROL UNIT
ORG/BLU WIRE
PNK WIRE
PNK/BRN WIRE
PS (+)
PYROFUSE
RED/GRN WIRE
RED/YEL WIRE
RIGHT REAR EMERGENCY TENSIONING RETRACTOR SQUIB
RIGHT REAR SEAT BELT BUCKLE SWITCH
RIGHT REAR SIDE BAG SQUIB
SAM CONTROL UNIT
SIG
SUPPLEMENTAL RESTRAINT SYSTEM CONTROL UNIT
UPPER PANEL CONTROL UNIT
VEHICLE INTERIOR FUSE BOX
VIO/BLU WIRE
VIO/GRN WIRE
W/O AUTOMATIC CHILD SEAT RECOGNITION
WEIGHT SENSING SYSTEM (WSS) CONTROL UNIT
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
ZP (+) GND
ZP (-)
Go to component -> Supplemental restraint circuit (1 of 4) -> UPPER PANEL CONTROL UNIT
