Transmission circuit for Mercedes-Benz C-class W205/S205/C205/A205 (2014-2018)

ANST AUDIO/COMAND CONTROL PANEL AUX BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/RED WIRE CAN A H CAN A L CAN B H CAN B L RBA-1 CAN HMI H CAN HMI L COMPUTER DATA LINES SYSTEM DIRECT SELECT LEVER DYNAMIC SELECT SWITCH ELECTRIC AUXILIARY OIL PUMP ELECTRONIC IGNITION SWITCH CONTROL UNIT ENGINE COMPARTMENT PREFUSE BOX FANFARE HORNS, AIR BAG CLOCK SPRING CONTACT FLEXRAY E 1 BP PNK FLEXRAY E 1 BM WIRE FRONT SAM CONTROL UNIT FULLY INTEGRATED TRANSMISSION CONTROL UNIT (IN BOTTOM OF TRANSMISSION) FUSE 105 FUSE 30 FUSE 304 FUSE 329 FUSE 454 GRN WIRE HOT AT ALL TIMES HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED HOT W/ VEHICLE INTERIOR TERMINAL 15 RELAY ENERGIZED INSTRUMENT CLUSTER INTELLIGENT SERVO MODULE FOR DIRECT SELECT INTERNAL INPUT SPEED RPM SENSOR LEFT LOWER CONTROL PANEL LIN LSP + OIL PUMP RELAY OUTPUT SHAFT RPM SENSOR REAR FUSE, RELAY MODULE RED WIRE RED/GRN WIRE RED/YEL WIRE RIGHT A-PILLAR FUSE BOX SELECTION RANGE SENSOR STEERING COLUMN MODULE CONTROL UNIT STEERING WHEEL DOWNSHIFT BUTTON STEERING WHEEL ELECTRONICS STEERING WHEEL UPSHIFT BUTTON TORQUE CONVERTER LOCKUP CLUTCH CONTROL SOLENOID VALVE TRANSMISSION OIL AUXILIARY PUMP CONTROL UNIT TRANSMISSION OIL TEMPERATURE SENSOR TURBINE WHEEL RPM SENSOR W/ AUXILIARY OIL PUMP WHT WIRE WORKING PRESSURE CONTROL SOLENOID VALVE YEL WIRE YEL/WHT WIRE
