Driver"s memory seat circuit for Mercedes-Benz C-class W205/S205/C205/A205 (2014-2018)

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/PNK WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE CAN B H CAN B L COMPUTER DATA LINES SYSTEM CRUISE CONTROL LEVER DRIVER SEAT BACKREST INCLINATION ADJUSTMENT MOTOR, HALL SENSOR DRIVER SEAT CONTROL UNIT DRIVER SEAT FORE/AFT ADJUSTMENT MOTOR, HALL SENSOR DRIVER SEAT HEAD RESTRAINT ADJUSTMENT MOTOR, HALL SENSOR FLEXRAY 1 BP FUSE 305 FUSE 327 FUSE 329 GRN WIRE GRY/BLK WIRE HK SL VL HOT AT ALL TIMES HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED LEFT BACKREST RELEASE/INCLINATION MICROSWITCH M+ (-) PNK FLEXRAY 1 BM WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE RESUME FROM MEMORY SWITCH RIGHT A-PILLAR FUSE BOX SEATS SYSTEM SIG STEERING COLUMN MEMORY CIRCUIT STEERING COLUMN MODULE CONTROL UNIT VIO WIRE VIO/BLK WIRE WHT WIRE YEL WIRE YEL/GRN WIRE

*** BLK WIRE BLK/BLU WIRE BLK/VIO WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/VIO WIRE CAN B H CAN B L COMPUTER DATA LINES SYSTEM DRIVER SEAT CONTROL UNIT DRIVER SEAT CUSHION LENGTH ADJUSTMENT MOTOR, HALL SENSOR DRIVER SEAT HEIGHT ADJUSTMENT MOTOR, HALL SENSOR DRIVER SEAT INCLINATION ADJUSTMENT MOTOR, HALL SENSOR FUSE 406 GRN WIRE GRN/VIO WIRE HOT AT ALL TIMES LEFT FRONT BACKREST ADJUSTMENT SWITCH LEFT FRONT DOOR CONTROL UNIT LEFT FRONT HEAD RESTRAINT ADJUSTMENT SWITCH LEFT FRONT SEAT ADJUSTMENT SWITCH GROUP LEFT FRONT SEAT CUSHION LENGTH SWITCH LEFT FRONT SEAT FORE/AFT ADJUSTMENT SWITCH LEFT FRONT SEAT HEIGHT ADJUSTMENT SWITCH LEFT FRONT SEAT INCLINATION ADJUSTMENT SWITCH M+ (-) MEMORY 1 SWITCH MEMORY 2 SWITCH MEMORY 3 SWITCH MEMORY FUNCTION SWITCH ORG/ WIRE REAR FUSE, RELAY MODULE RED WIRE RED/BLU WIRE RED/VIO WIRE SEAT HEATER SEATS SYSTEM SIG VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
