Data link connector circuit for Mercedes-Benz C-class W205/S205/C205/A205 (2014-2018)

BLU WIRE BRN WIRE CAN-D H CAN-D L DIAGNOSTIC CONNECTOR ELECTRONIC IGNITION SWITCH CONTROL UNIT ELECTRONIC STABILITY PROGRAM CONTROL UNIT EMERGENCY CALL SYSTEM CONTROL UNIT ETN RX+ ETN TX+ FUSE 204 GRN WIRE GRY WIRE GRY/WHT WIRE HEAD UNIT HERMES CONTROL UNIT HOT AT ALL TIMES K LINE LEFT FUSE, RELAY MODULE ORG/ WIRE PNK WIRE RED/GRN WIRE TELEMATICS SERVICES COMMUNICATION MODULE W/ EMERGENCY CALL/ ASSISTANCE SYSTEM W/ HERMES W/ TELEMATICS WAKEUP WHT WIRE WHT/BLK WIRE YEL/GRY WIRE
