Anti-theft circuit for Mercedes-Benz C-class W204/S204/С204 facelift (2011-2015)

12 13 17 18 CAN E L CAN E H CAN B L CAN B H 2 3 1 31 LIN 1 30 30 31 5 CAN B H CAN B L EMD 4 3 2 1 S_GB 30 6 5 4 3 2 1 ASS OFF ASS LED 31 6 5 4 3 2 1 OFF INTERIOR PROTECTION SWITCH ANTI-THEFT ALARM SYSTEM INDICATOR LAMP INSTRUMENT PANEL SWITCH GROUP BLK WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/PNK WIRE BRN WIRE BRN/BLK WIRE BRN/GRY WIRE BRN/RED WIRE BRN/WHT WIRE CAN B L CAN B H CAN-B H CAN-B L COMPUTER DATA LINES SYSTEM EMERGENCY CALL SYSTEM CONTROL UNIT (CENTER FRONT OF TRUNK/CARGO AREA) FAN RELAY MODULE FRONT ELECTRICAL PREFUSE BOX (RIGHT REAR OF ENGINE COMPT) FUSE FUSE 17 FUSE 18 GRN WIRE GRN/WHT WIRE GRY/YEL WIRE HORNS SYSTEM HOT AT ALL TIMES HOT W/ QUIESCENT CURRENT CUTOUT RELAY ENERGIZED INFO INFO LED INSTRUMENT CLUSTER INTERIOR LEFT INTERIOR PROTECTION PROTECTION RECEIVER TRANSMITTER INTERIOR PROTECTION, TOW-AWAY PROTECTION CONTROL UNIT (IF EQUIPPED) IRS LED IRS-OFF LEFT ENGINE HOOD CONTACT SWITCH (LEFT FRONT CORNER OF ENGINE COMPT) MULTI-FUNCTION DISPLAY NCA WIRE OFF TOWING SENSOR BUTTON 8 7 6 4 3 2 SOS LED WS LED INFO LED WS INFO SOS REAR SAM CONTROL MODULE W/ FUSE, RELAY MODULE (RIGHT SIDE OF TRUNK/CARGO AREA) REAR WINDOW GLASS BREAKAGE SENSOR RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RIGHT INTERIOR PROTECTION TRANSMITTER RIGHT REAR WINDOW GLASS BREAKAGE SENSOR SOS SOS LED W/ ECO START/ STOP FUNCTION W/O ECO START/ STOP FUNCTION WHT WIRE WS LED YEL WIRE YEL/RED WIRE YEL/VIO WIRE
