Heated seats circuit for Mercedes-Benz C-class W203/S203/CL203 facelift (2004-2008)

1 2 3 4 31 30 CAN-B L CAN-B H 4 1 2 30 RF HTD SEAT LF HTD SEAT BLK/GRY WIRE BLK/VIO WIRE BLU WIRE BRN WIRE BRN/RED WIRE COMFORT AAC PUSHBUTTON CONTROL MODULE COMPUTER DATA LINES SYSTEM FUSE 25 FUSE 41 GRN WIRE HOT AT ALL TIMES INTERIOR FUSE BOX (LEFT END OF DASH) LEFT FRONT HEATED SEAT SWITCHES LEFT LEFT FRONT FRONT HEATED HEATED BACKREST SEAT CUSHION CUSHION NCA WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RIGHT FRONT HEATED BACKREST CUSHION RIGHT FRONT HEATED SEAT CUSHION RIGHT FRONT HEATED SEAT SWITCHES UPPER CONTROL PANEL CONTROL MODULE
